FHL36050 - 50 Amp Circuit Breaker

FHL36050 - 50 Amp Circuit Breaker

Experience dependable circuit protection with the FHL36050 from Schneider Electric, a top‑tier 3‑pole, 50-amp thermal‑magnetic molded‑case circuit breaker built for demanding commercial and industrial environments. Whether for large HVAC loads, manufacturing equipment, or high‑capacity distribution panels, this breaker delivers the safety, interruption capacity, and installation flexibility your operations need. With its feed‑through design and unit‑mount configuration, it integrates smoothly into your panel layout and provides peace of mind knowing you’re backed by a trusted electrical equipment manufacturer.

Key Features and Benefits

• Thermal‑magnetic trip technology: Ensures rapid response to both sustained overloads and instantaneous short‑circuit conditions.
• High breaking capacity (Code “H”): Delivers robust protection in high fault‑current environments, safeguarding critical infrastructure and equipment.
• Feed‑through terminal design: Allows both load and line side connections, simplifying wiring and enabling cleaner panel builds.
• Compact size for its rating: Only 6.4″ H × 4.5″ W × 4.13″ D — making it suitable for tight panel layouts without sacrificing performance.
• Lugs accommodate copper AWG 14…1/0 and aluminum AWG 12…1/0 conductors: On both line and load sides, offering broad wiring flexibility.
• Backed by Schneider Electric’s Green Premium certified label and compliance declarations: Great for facilities tracking sustainability and regulatory compliance.

Technical Specifications

• Line Rated Current: 50 Amp
• Poles: 3 (three‑phase)
• Breaking Capacity:
  • 65 kA @ 240 V AC
  • 25 kA @ 480 V AC
  • 18 kA @ 600 V AC
  • 10 kA @ 250 V DC
• Trip Unit Technology: Thermal‑Magnetic
• Magnetic Hold Current: ~400 A
• Magnetic Tripping Current: ~850 A
• Mounting Mode: Unit‑mount panel configuration
• Terminals: Line and load lugs, terminal identifier AL100FA
• Dimensions:
  • Height: 6.4 in (162.6 mm)
  • Width: 4.5 in (114.3 mm)
  • Depth: 4.13 in (104.9 mm)

Material Compliance and Certifications

• Certified to CSA and UL listings: For peace‑of‑mind in demanding environments.
• Green Premium‑certified: Complying with RoHS and REACh requirements, reflecting a lower‑impact, recyclability‑ready design.

Where It Works Best

• If you’re managing large commercial or industrial electrical installations, the FHL36050 is an excellent fit. Use it for high‑demand equipment like HVAC systems, manufacturing lines, large motor control centers, or critical branch circuits where high fault‑current interruption is essential. Its feed‑through design and broad wiring capacity make it highly suitable for upgrade projects, panel retrofits, or new installations where space is limited but performance can’t be compromised.
