FHL36035 - 35 Amp Circuit Breaker

FHL36035 - 35 Amp Circuit Breaker

When your circuit breaker fails, trips repeatedly, or needs replacement during scheduled maintenance, choosing the correct replacement is about much more than matching the amperage. The Square D FHL36035 is designed to help maintain existing electrical distribution systems by providing the correct form, fit, and function for compatible equipment. Before replacing a breaker, verify the catalog number, 35 Amp rating, 600V AC voltage, 3-pole configuration, breaking capacity code, and unit mount design to ensure the replacement matches the original installation.

Key Features and Benefits

• 35 Amp continuous current rating
• Three-pole design for three-phase electrical systems
• 600V AC voltage rating
• Thermal-magnetic trip technology provides overload and short-circuit protection
• Unit mount configuration for compatible Square D I-Line panelboards
• Line and load lug terminations simplify installation into compatible equipment
• HACR rated for heating, air conditioning, and refrigeration applications
• Helps maintain the original form, fit, and function of existing equipment
• Suitable for maintaining commercial and industrial electrical distribution systems
• Built to last for dependable long service life


Technical Specifications

• Catalog Number: FHL36035

• Manufacturer: Square D

• Product Type: Circuit Breaker

• Series: FHL

• Trip Unit Technology: Thermal-Magnetic

• Amperage Rating: 35 Amps

• Voltage Rating: 600V AC

• Number of Poles: 3

• Phase Connection: ABC (Three-Phase)

• Breaking Capacity Code: H

• Mounting Style: Unit Mount

• Electrical Connections: Line Lugs and Load Lugs

• Terminal Identifier: AL100FA

• Magnetic Hold Current: 400 Amps

• Magnetic Tripping Current: 850 Amps

• Application Rating: HACR Rated

• Dimensions: 6.40 in. H × 4.50 in. W × 4.13 in. D


Material Compliance and Certifications

The Square D FHL36035 is UL Listed and CSA Certified, meeting recognized North American electrical safety standards. It is intended for use in compatible equipment and should be installed in accordance with the National Electrical Code (NEC) and all applicable local electrical codes. Installation and maintenance should always be performed by qualified electrical personnel using accepted electrical safety practices.

Where It Works Best

• Compatible Square D I-Line panelboards
• Commercial electrical systems
• Industrial electrical systems
• Existing electrical distribution systems
• HVAC equipment
• Heating and air conditioning systems
• Refrigeration equipment
• Three-phase motor circuits
• Pumps and compressors
• Manufacturing facilities
• Processing plants
• Commercial buildings
• Branch circuit protection
