FDC3090L 90A Circuit Breaker

FDC3090L 90A Circuit Breaker

The Eaton FDC3090L is a robust and reliable molded case circuit breaker from the esteemed Series C line, specifically designed for high-performance and safety in demanding electrical applications. Engineered with a fixed thermal and magnetic trip type, this three-pole breaker delivers a dependable 90 amps of current handling capacity at 600 VAC and 250 VDC, ensuring optimal performance and protection for your electrical systems. This circuit breaker is designed for both line and load applications and operates efficiently at a frequency rating of 50/60 Hz, providing flexibility and reliability in various power distribution scenarios.

Key Features and Benefits:

• High Current Capacity: Rated at 90A, this circuit breaker can handle substantial electrical loads, ensuring the safety and reliability of your electrical systems.
• Robust Interrupting Capacity: With 200 kAIC at 240 VAC and 100 kAIC at 480 VAC, it offers superior protection against electrical faults, minimizing downtime and enhancing safety.
• Fixed Thermal and Magnetic Trip: Ensures consistent and reliable operation, providing essential protection for your electrical circuits.
• Versatile Application: Suitable for both line and load applications, making it ideal for a wide range of industrial and commercial uses.

Technical Specifications:

• Amperage Rating: 90A
• Voltage Rating: 600 VAC, 250 VDC
• Interrupting Capacity: 200 kAIC at 240 VAC, 100 kAIC at 480 VAC
• Trip Type: Fixed Thermal, Fixed Magnetic
• Number of Poles: 3
• Frequency Rating: 50/60 Hz
• Dimensions: 3.38 in (L) x 6 in (H) x 4.13 in (W)
• Weight: 4.5 lb

Material Compliance and Certifications:

• UL Listed: Ensures compliance with rigorous safety standards, enhancing trust and reliability.
• Certifications: Detailed certification information available through Eaton’s resources, including the UL listed 100%-rated molded case circuit breakers and various product aids for specialized applications.

Suitability:

• The Eaton FDC3090L circuit breaker is perfectly suited for use in industrial and commercial electrical systems where high reliability and performance are paramount. Whether in manufacturing plants, commercial buildings, or other demanding environments, the FDC3090L ensures the safety and efficiency of your electrical infrastructure.
