FD63T225 - 225Amp Trip Unit

FD63T225 - 225Amp Trip Unit

When an electrical system needs reliable protection at the 225 amp level, selecting the right breaker is an important step in keeping equipment and operations running safely. The FD63T225 Siemens circuit breaker is a 225 Amp, 3-pole molded case circuit breaker designed for commercial and industrial electrical distribution systems where dependable overcurrent protection is required. Built as part of the Siemens SENTRON FD frame family, this breaker helps protect electrical equipment, feeders, and distribution circuits from overloads and short-circuit conditions while delivering the trusted performance expected from Siemens.

Whether you are replacing an existing breaker, upgrading a power distribution system, or completing a new electrical installation, the Siemens FD63T225 molded case circuit breaker provides a reliable solution.

Key Features and Benefits

• 225 Amp, 3-pole Siemens SENTRON molded case circuit breaker
• Designed for commercial and industrial electrical distribution systems
• Thermal magnetic trip technology provides overload and short-circuit protection
• Rated for 600 VAC electrical systems
• 22kAIC interrupting capacity at 600V
• 35kAIC interrupting capacity at 480V
• Includes line and load side lugs for easier installation
• Supports both copper and aluminum conductors
• Accepts 6 AWG–350 kcmil copper wire
• Accepts 4 AWG–350 kcmil aluminum wire
• Siemens FD frame design for compatible electrical equipment


Technical Specifications

• Catalog Number: FD63T225

• Manufacturer: Siemens

• Product Type: Molded Case Circuit Breaker (MCCB)

• Series: Siemens SENTRON FD Frame

• Frame Size: FD6

• Amperage Rating: 225 Amps

• Number of Poles: 3

• Voltage Rating: 600 VAC

• Interrupting Capacity:
  • 22 kAIC at 600V
  • 35 kAIC at 480V
• Trip Unit: Thermal Magnetic

• Temperature Rating: 40°C Standard

• Connection Type: Line and Load Side Lugs Included

• Lug Type: TA1FD350A

• Wire Range:
  • Copper: 6 AWG–350 kcmil
  • Aluminum: 4 AWG–350 kcmil
• Standards: UL 489 / IEC 60947-2

• Dimensions: 4.5 in W x 9.5 in H x 4 in D

• Weight: 1.199 lb

• UPC: 783643211988


Material Compliance and Certifications

The Siemens FD63T225 molded case circuit breaker is designed to meet recognized electrical safety and performance requirements, including UL 489 and IEC 60947-2 standards. These certifications help verify that the breaker has been evaluated for applications requiring dependable overcurrent protection and safe electrical operation.

Where It Works Best

• Commercial electrical distribution systems
• Industrial facilities and manufacturing environments
• Three-phase 600V power applications
• Equipment feeder protection
• Electrical panels and distribution assemblies
• Siemens FD frame breaker replacement projects
• Applications requiring 225 amp circuit protection
• Systems using copper or aluminum conductors
• Electrical maintenance and upgrade projects
