FD63B080 - 80Amp Circuit Breaker

FD63B080 - 80Amp Circuit Breaker

The Siemens FD63B080 is a top-tier low voltage molded case circuit breaker from the SENTRON series, featuring a thermal-magnetic trip unit. With a robust 80A rating and a 3-pole configuration, the FD63B080 provides dependable protection for your electrical systems.

Key Features and Benefits:

• Thermal-Magnetic Trip Unit: Offers precise protection against overloads and short circuits.
• Standard Breaking Capacity: Ensures reliable performance in various applications.
• UL 489 / IEC 60947-2 Standards Compliance: Meets high safety and performance standards.
• Line and Load Side Lugs: Simplifies installation and enhances connection reliability.
• Wide Wire Range: Accommodates 6AWG - 350KCM copper and 4AWG - 350KCM aluminum wires.
• Compact Design: Fits easily into tight spaces without compromising performance.

Technical Specifications:

• Amperage: 80A
• Poles: 3
• Voltage Ratings: 22kAIC at 600V, 35kAIC at 480V
• Dimensions: 4.5 inches (W) x 9.5 inches (H) x 4 inches (D)
• Wire Range: 6AWG - 350KCM (CU), 4AWG - 350KCM (AL)
• Weight: 8.973 lb

Material Compliance and Certifications:

• RoHS Compliance: Meets the substance restrictions as per the RoHS directive since July 18, 2019.
• WEEE Compliance: Adheres to the WEEE Take-Back Obligation as per the 2012/19/EU directive.
• REACH Compliance: Complies with the current list of candidates under REACH Article 33.

Suitability:

• The Siemens FD63B080 circuit breaker is ideal for a wide range of applications, including industrial and commercial electrical systems that require reliable protection and compliance with international safety standards. Its compact size and high performance make it suitable for use in panelboards, switchboards, and motor control centers, providing excellent protection for motors, transformers, and other electrical components.
