FD62T150 - 150Amp Trip Unit

FD62T150 - 150Amp Trip Unit

The Siemens FD62T150 is a 150 Amp thermal-magnetic trip unit for compatible FD-frame molded case circuit breakers. The trip unit is a key part of the breaker assembly because it determines the breaker’s overload and short-circuit protection settings. Matching the correct trip unit to the FD frame and amp rating helps keep your breaker operating with the specifications it was built for.

This Siemens trip unit provides thermal protection for overload conditions and magnetic protection for short-circuit events. The FD62T150 is rated for 600 VAC and is used with breaker configurations rated for 22 kAIC at 600V and 35 kAIC at 480V.

Built for FD-frame breaker applications, the FD62T150 supports configurations using line- and load-side lug connections and accommodates larger conductors, including 6 AWG to 350 kcmil copper wire and 4 AWG to 350 kcmil aluminum wire.

Key Features and Benefits

• Siemens FD-frame thermal-magnetic trip unit
• Catalog Number: FD62T150
• 150 Amp rating
• Two-pole configuration
• Provides overload and short-circuit protection
• Rated for 600 VAC
• Meets UL 489 and IEC 60947-2 standards


Technical Specifications

• Manufacturer: Siemens

• Catalog Number: FD62T150

• Product Type: Thermal-Magnetic Trip Unit

• Frame Compatibility: FD

• Amperage Rating: 150 Amps

• Number of Poles: 2

• Trip Type: Thermal-Magnetic

• Voltage Rating: 600 VAC

• Interrupting Rating:
  • 22 kAIC at 600 VAC
  • 35 kAIC at 480 VAC
• Terminal Configuration: Line and Load Side Lug Applications

• Wire Range:
  • Copper: 6 AWG – 350 kcmil
  • Aluminum: 4 AWG – 350 kcmil
• Dimensions: 4.5 in. W × 9.5 in. H × 4 in. D

• Weight: Approximately 1.08 lbs

• UPC: 783643211605


Material Compliance and Certifications

The Siemens FD62T150 is designed to meet UL 489 and IEC 60947-2 standards for molded case circuit breaker applications. Before installation, confirm that the trip unit matches the FD-frame breaker, amp rating, voltage rating, and overall breaker configuration.

Where It Works Best

The Siemens FD62T150 is commonly used in commercial buildings, industrial facilities, and electrical distribution equipment that uses compatible FD-frame molded case circuit breakers.
