FD62T110 - 110Amp Trip Unit

FD62T110 - 110Amp Trip Unit

The Siemens FD62T110 is a robust and reliable low-voltage molded case circuit breaker designed to ensure the safe and efficient operation of electrical systems. This is only a trip unit, it needs a compatible frame to function as a circuit breaker.

Key Features and Benefits:

• Thermal-Magnetic Trip Unit: Offers reliable protection by combining thermal and magnetic tripping mechanisms to handle both prolonged overloads and instantaneous short circuits.
• High Breaking Capacity: Rated at 22kAIC at 600V and 35kAIC at 480V, providing high interrupting performance for enhanced safety and reliability in demanding environments.
• Versatile Lug Options: Includes line and load side lugs (TA1FD350A) with a wide wire range of 6AWG - 350KCM (CU) and 4AWG - 350KCM (AL), offering flexibility for various installation requirements.

Technical Specifications:

• Amperage Rating: 110A
• Poles: 2
• Breaking Capacity: 22kAIC at 600V, 35kAIC at 480V
• Wire Range: 6AWG - 350KCM (Copper), 4AWG - 350KCM (Aluminum)
• Dimensions: 4.5 x 9.5 x 4 inches
• Weight: 1.1 lbs
• Special Features: Line and load side lugs (TA1FD350A)

Material Compliance and Certifications:

• RoHS Compliant: Yes, since 04/03/2009, ensuring the product is free from hazardous substances.
• REACH Compliance: Fulfills the requirements for the regulation on Registration, Evaluation, Authorization, and Restriction of Chemicals.
• WEEE Directive: Complies with the Waste Electrical and Electronic Equipment Directive (2012/19/EU), ensuring responsible disposal and recycling of electrical equipment.

Suitability:

• Ideal for protecting electrical circuits in commercial facilities, ensuring safety and reliability.åÊSuitable for heavy-duty applications in industrial environments where high breaking capacity and robust performance are crucial.åÊPerfect for inclusion in custom-built electrical panels, providing dependable protection and compliance with industry standards.åÊA reliable choice for maintenance professionals looking to replace or upgrade existing circuit breakers in various electrical systems.

By choosing the Siemens FD62T110 circuit breaker, you are ensuring a high level of protection and reliability for your electrical installations.
