FD62T090 - 90Amp Trip Unit

FD62T090 - 90Amp Trip Unit

The Siemens FD62T090 is a thermal-magnetic trip unit designed for use with a compatible frame to function as a complete circuit breaker. This is only a trip unit, it needs a compatible frame to function as a circuit breaker.

Key Features and Benefits:

• Thermal-Magnetic Trip Unit: Provides dual protection with thermal overload and magnetic short-circuit protection, enhancing safety and reliability.
• High Breaking Capacity: Withstands high fault currents with 22KAIC at 600V and 35KAIC at 480V, ensuring consistent performance under demanding conditions.
• Versatile Connectivity: Equipped with line and load side lugs (TA1FD350A), accommodating a wide wire range from 6AWG to 350KCM (CU) and 4AWG to 350KCM (AL).

Technical Specifications:

• Current Rating: 90A
• Number of Poles: 2
• Voltage Rating: 600V
• Interrupting Capacity: 22KAIC at 600V, 35KAIC at 480V
• Dimensions: 4.5 x 9.5 x 4 inches
• Weight: 1.1 lb
• Wire Range: 6AWG - 350KCM (CU) / 4AWG - 350KCM (AL)
• Trip Unit: Thermal-Magnetic

Material Compliance and Certifications:

• UL 489 Certified: Ensures compliance with North American safety standards for low voltage circuit breakers.
• IEC 60947-2 Compliant: Meets international standards for low-voltage switchgear and controlgear.
• RoHS Directive: Compliant since April 3, 2009, ensuring the restriction of hazardous substances in electrical and electronic equipment.
• WEEE Directive: Complies with the Waste Electrical and Electronic Equipment Directive (2012/19/EU), ensuring environmentally sound disposal.

Suitability:

• Ideal for use in commercial buildings, industrial facilities, high-demand residential settings, and renewable energy systems such as solar power installations. Provides reliable protection when paired with a compatible frame for use as a circuit breaker.
