FD62T070 - 70Amp Trip Unit

FD62T070 - 70Amp Trip Unit

The Siemens FD62T070 is a 70 Amp thermal-magnetic trip unit designed for use with compatible FD-frame molded case circuit breakers. For breaker maintenance and service work, choosing the correct trip unit is critical because the amp rating, frame compatibility, trip characteristics, and electrical ratings all need to match your breaker assembly.

This Siemens trip unit provides thermal-magnetic protection, helping the breaker respond to both overload conditions and short-circuit events. It is rated for 600 VAC with interrupting ratings of 22 kAIC at 600V and 35 kAIC at 480V when installed in the proper FD-frame breaker configuration.

The FD62T070 is designed for FD-frame applications and supports breaker configurations using larger conductor ranges, including 6 AWG to 350 kcmil copper wire and 4 AWG to 350 kcmil aluminum wire.

Key Features and Benefits

• Siemens FD-frame thermal-magnetic trip unit
• Catalog Number: FD62T070
• 70 Amp rating
• Two-pole configuration
• Provides thermal and magnetic protection
• Designed for compatible FD-frame molded case circuit breakers
• Rated for 600 VAC
• Meets UL 489 and IEC 60947-2 standards


Technical Specifications

• Manufacturer: Siemens

• Catalog Number: FD62T070

• Product Type: Thermal-Magnetic Trip Unit

• Breaker Frame Compatibility: FD

• Amperage Rating: 70 Amps

• Number of Poles: 2

• Trip Type: Thermal-Magnetic

• Voltage Rating: 600 VAC

• Interrupting Rating:
  • 22 kAIC at 600 VAC
  • 35 kAIC at 480 VAC
• Wire Range:
  • Copper: 6 AWG – 350 kcmil
  • Aluminum: 4 AWG – 350 kcmil
• Dimensions: 4.5 in. W × 9.5 in. H × 4 in. D

• Weight: Approximately 1.1 lbs

• UPC: 783643211544


Material Compliance and Certifications

The Siemens FD62T070 is designed to meet UL 489 and IEC 60947-2 standards for molded case circuit breaker applications. Before installation, confirm that the trip unit matches the breaker frame, amp rating, and overall breaker configuration.

Where It Works Best

The Siemens FD62T070 is commonly used in commercial buildings, industrial facilities, and electrical distribution equipment that uses compatible Siemens FD-frame molded case circuit breakers. It is a practical component for maintenance and repair work where the existing breaker design and protection requirements need to remain consistent.
