FD62B090 - 90Amp Circuit Breaker

FD62B090 - 90Amp Circuit Breaker

The Siemens FD62B090 Circuit Breaker is a top-of-the-line solution designed for reliable performance in commercial and industrial applications. This 90A, 2-pole circuit breaker is part of the SENTRON series, known for its robust construction and advanced safety features. Whether you are looking to enhance the safety of your electrical systems or need a dependable breaker for new installations, the FD62B090 is an excellent choice.

Key Features and Benefits

• Thermal-Magnetic Trip Unit: Provides accurate overload and short-circuit protection, ensuring the safety and longevity of your electrical systems.
• Standard Breaking Capacity: Equipped with a standard breaking capacity of 22KAIC at 600V and 35KAIC at 480V, making it suitable for a wide range of applications.
• Versatile Lug Options: Comes with line and load side lugs (TA1FD350A) that accommodate wire ranges from 6AWG to 350KCM for copper and 4AWG to 350KCM for aluminum, offering flexibility in installation.

Technical Specifications

• Frame Type: FD Frame
• Rated Current: 90 Amps
• Number of Poles: 2
• Voltage Rating: Up to 600V
• Breaking Capacity: 22KAIC at 600V, 35KAIC at 480V
• Weight: 8.157 lbs
• Dimensions (W x H x D): 4.5 x 9.5 x 4 inches
• Wire Range: 6AWG - 350KCM (Copper), 4AWG - 350KCM (Aluminum)

Material Compliance and Certifications

• The Siemens FD62B090 Circuit Breaker is designed with material compliance in mind. It adheres to the highest industry standards, ensuring safety and reliability in every use. The product meets the UL 489 and IEC 60947-2 standards, providing peace of mind that it has been rigorously tested for performance and safety. It also complies with environmental regulations, including the RoHS directive, ensuring it is free from hazardous substances.

Suitability

• This circuit breaker is ideal for use in commercial buildings, industrial plants, and other settings where reliable electrical protection is crucial. Its robust design and high breaking capacity make it suitable for a wide range of applications, including HVAC systems, motor control centers, and lighting panels. The versatility in lug options and compliance with international standards make it a preferred choice for electrical contractors and engineers looking for dependable circuit protection.
