FD62B080L - 80Amp Circuit Breaker

FD62B080L - 80Amp Circuit Breaker

The FD62B080L Siemens Low Voltage Sentron Molded Case Circuit Breaker with Thermal-Magnetic Trip Unit is an essential component for ensuring electrical safety and reliability in commercial and industrial applications.

Key Features and Benefits

• Thermal-Magnetic Trip Unit: Provides reliable protection against overloads and short circuits, ensuring the safety of electrical systems.
• High Breaking Capacity: Capable of handling up to 22KAIC at 600V and 35KAIC at 480V, making it suitable for demanding environments.
• Versatile Lug Options: Equipped with line and load side lugs (TA1FD350A) that support a wire range of 6AWG - 350KCM (CU) / 4AWG - 350KCM (AL), offering flexibility in installation.

Technical Specifications

• Current Rating: 80 Amps
• Poles: 2
• Breaking Capacity: 22KAIC at 600V, 35KAIC at 480V
• Standards Compliance: UL 489, IEC 60947-2
• Trip Unit: Thermal-Magnetic
• Dimensions: 4.5 x 9.5 x 4 inches
• Wire Range: 6AWG - 350KCM (CU) / 4AWG - 350KCM (AL)
• Lug Type: TA1FD350A (line and load side)

Material Compliance and Certifications

• REACH Compliance: Duty to inform according to the current list of candidates
• WEEE Directive: Yes, compliant with the 2012/19/EU take-back obligation

Suitability

• The FD62B080L circuit breaker is perfect for use in commercial buildings, industrial facilities, and other environments where reliable electrical protection is paramount. Its robust design and compliance with international standards make it a dependable choice for protecting electrical circuits from damage caused by overloads and short circuits.
