FD3225 225A Circuit Breaker

FD3225 225A Circuit Breaker

The Eaton FD3225 is a high-performance molded case circuit breaker designed to provide reliable and efficient protection for electrical systems. As part of Eaton's Series C F-frame circuit breakers, the FD3225 combines robust construction with advanced features to ensure optimal performance and safety. This three-pole breaker offers a fixed thermal and fixed magnetic trip, delivering consistent and precise overcurrent protection for a wide range of applications. With a current rating of 225 A and voltage ratings of 600 V AC and 250 V DC, the FD3225 is built to handle demanding electrical environments, making it an ideal choice for both commercial and industrial settings.

Key Features and Benefits:

• High Interrupting Capacity: The FD3225 boasts a high interrupting capacity of 65 kAIC at 240 V AC and 35 kAIC at 480 V AC, providing robust protection against short circuits and overloads.
• Fixed Thermal and Magnetic Trip: The fixed thermal and magnetic trip mechanisms ensure consistent performance, reducing the risk of electrical failures and enhancing system reliability.
• Versatile Applications: Suitable for use in various commercial and industrial applications, the FD3225 is engineered to meet the demands of modern electrical systems, ensuring safety and efficiency.

Technical Specifications:

• Series: Eaton Series C F-frame
• Poles: Three-pole
• Amperage Rating: 225 A
• Voltage Ratings: 600 V AC, 250 V DC
• Interrupting Capacity: 65 kAIC at 240 V AC, 35 kAIC at 480 V AC
• Frequency Rating: 50 to 60 Hz
• Trip Type: Fixed thermal, fixed magnetic
• Dimensions: 3.38" (L) x 6" (H) x 4.13" (W)
• Weight: 4.5 lbs

Material Compliance and Certifications:

• Compliance: The Eaton FD3225 circuit breaker is UL listed, ensuring it meets rigorous safety and performance standards. Eaton’s commitment to quality and compliance ensures that this circuit breaker adheres to industry regulations, providing peace of mind and reliable protection for your electrical systems.

Suitability:

• The Eaton FD3225 is perfectly suited for use in commercial buildings, industrial facilities, and other applications requiring high reliability and robust protection. Its high interrupting capacity and durable design make it an excellent choice for protecting circuits in challenging environments, ensuring safety and continuity of service.
