FD3200L - 200Amp Circuit Breaker

FD3200L - 200Amp Circuit Breaker

The Eaton FD3200L Series C molded case circuit breaker offers superior protection with its 200-amp capacity and three-pole configuration, making it an excellent choice for high-demand industrial and commercial applications. Designed with fixed thermal and magnetic trip technology, this F-frame breaker delivers fast, reliable overload and short-circuit protection.

Key Features and Benefits:

• High Capacity Protection: 200-amp rating with three-pole configuration provides dependable overload and short-circuit protection.
• Durable and Efficient: Engineered with fixed thermal and magnetic trip units for reliable performance in demanding environments.
• High Interrupt Rating: With 65 kAIC at 240 Vac and 35 kAIC at 480 Vac, it offers excellent fault tolerance, ensuring system integrity under high fault currents.

Technical Specifications:

• Amperage: 200 A
• Voltage: 600 Vac, 250 Vdc
• Trip Type: Fixed thermal, fixed magnetic
• Configuration: Three-pole
• Frame: F-frame, Series C
• Frequency Rating: 50-60 Hz
• Interrupt Ratings: 65 kAIC at 240 Vac, 35 kAIC at 480 Vac
• Dimensions: Length: 3.38 in, Width: 4.13 in, Height: 6 in
• Weight: 4.5 lb
• Terminals: Line and load terminals

Material Compliance and Certifications:

• The Eaton FD3200L is UL Listed, ensuring it meets industry safety standards for dependable performance in diverse applications. This breaker is backed by Eaton's warranty, covering one year from installation or 18 months from shipment.

Suitability:

• Ideal for commercial and industrial applications, the Eaton FD3200L circuit breaker is designed to meet high-capacity demands, providing exceptional protection in electrical systems with rigorous operational requirements. Suitable for contractors and facility managers looking for a durable and compliant solution.
