FD3175 **Older Style 25k** 175A Circuit Breaker

FD3175 **Older Style 25k** 175A Circuit Breaker

Introducing the Eaton FD3175, a high-performance circuit breaker from the renowned Eaton Series C range, designed to ensure optimal protection and efficiency for your electrical systems. This molded case circuit breaker is engineered to meet the demanding requirements of industrial and commercial applications, providing reliable performance and enhanced safety.

Key Features and Benefits

• Durable Construction: Built with a fixed thermal and fixed magnetic trip type, this breaker ensures long-lasting reliability and consistent performance, reducing the need for frequent maintenance.
• Versatile Application: Suitable for both AC and DC applications, the FD3175 operates efficiently at 600 Vac and 250 Vdc, making it a versatile choice for various power distribution needs.
• Compact Design: With dimensions of 3.38 inches in length, 6 inches in height, and 4.13 inches in width, this breaker is designed for easy installation and space-saving in electrical panels.

Technical Specifications

• Series: Eaton Series C
• Frame Type: F-frame, FD
• Poles: Three-pole
• Amperage Rating: 175 A
• Voltage Rating: 600 Vac, 250 Vdc
• Interrupt Rating: 65k @ 240VAC; 25k @ 480VAC
• Trip Type: Fixed thermal, fixed magnetic
• Dimensions: Length: 3.38 in, Height: 6 in, Width: 4.13 in
• Weight: 4.5 lb

Material Compliance and Certifications

• Compliance: The Eaton FD3175 circuit breaker is UL Listed, ensuring it meets stringent safety and performance standards. Eaton’s commitment to quality is reflected in this breaker’s compliance with industry regulations, making it a reliable choice for your electrical systems.

Suitability

• This circuit breaker is ideal for a wide range of applications, including industrial facilities, commercial buildings, and large-scale power distribution networks. Its robust design and high interrupting capacity make it suitable for protecting critical electrical circuits, ensuring uninterrupted power and enhanced safety.
