FD3150L 150A Circuit Breaker

FD3150L 150A Circuit Breaker

Introducing the Eaton FD3150L Series C Molded Case Circuit Breaker, an essential component for ensuring reliable and efficient electrical distribution in commercial and industrial settings. Designed to deliver superior performance, the FD3150L circuit breaker is built with a robust thermal magnetic trip unit, providing precise protection against overloads and short circuits. With a 150A current rating and three-pole configuration, this breaker ensures optimal power distribution, making it ideal for high-demand applications.

Key Features and Benefits:

• High Current Rating: Supports up to 150A, perfect for demanding electrical systems.
• Thermal Magnetic Trip: Combines thermal protection for overload conditions and magnetic protection for short circuits, enhancing system reliability.
• Superior Interrupting Capacity: Rated at 35 kAIC at 480 Vac and 65 kAIC at 240 Vac, ensuring safe operation in various fault conditions.

Technical Specifications:

• Voltage Rating: 600 Vac, 250 Vdc
• Amperage: 150A
• Frequency Rating: 50/60 Hz
• Poles: Three-pole

Material Compliance and Certifications:

• Compliance: The FD3150L circuit breaker is UL Listed, guaranteeing adherence to rigorous safety standards. Eaton's commitment to quality and safety is reflected in their comprehensive warranty policy and the product's robust certification credentials.

Suitability:

• Ideal for a wide range of commercial and industrial applications, the FD3150L is perfect for use in panelboards, switchboards, and motor control centers. Its reliable performance and high interrupting capacity make it suitable for protecting electrical systems in factories, warehouses, and large office buildings. Whether it's for new installations or replacing outdated breakers, the FD3150L provides unmatched reliability and protection.
