FD3150 150A Circuit Breaker

FD3150 150A Circuit Breaker

Introducing the Eaton Series C FD3150 Circuit Breaker, a high-performance, three-pole molded case circuit breaker designed to provide robust protection for your electrical systems. Engineered with a fixed thermal and magnetic trip type, this circuit breaker offers reliable overcurrent protection, ensuring the safety and efficiency of your electrical infrastructure. With a capacity of 150A, the FD3150 is suitable for a variety of applications, operating at 600 Vac and 250 Vdc. It boasts an impressive interrupt rating of 65 kAIC at 240 Vac and 35 kAIC at 480 Vac, making it an ideal choice for both commercial and industrial settings.

Key Features and Benefits:

• High Interrupt Rating: The FD3150's high interrupt ratings of 65 kAIC at 240 Vac and 35 kAIC at 480 Vac ensure superior performance and protection in demanding environments.
• Fixed Thermal and Magnetic Trip: This circuit breaker features fixed thermal and magnetic trip settings, providing consistent and reliable protection against overloads and short circuits.
• Versatile Application: With a voltage rating of 600 Vac and 250 Vdc, and a current rating of 150A, the FD3150 is versatile and suitable for a wide range of applications.
• Durable Construction: Engineered with high-quality materials, this breaker ensures long-lasting durability and performance, making it a cost-effective solution for your electrical protection needs.

Technical Specifications:

• Series: Eaton Series C
• Frame Type: F-frame
• Trip Type: Fixed Thermal, Fixed Magnetic
• Number of Poles: 3
• Current Rating: 150A
• Voltage Rating: 600 Vac, 250 Vdc
• Interrupt Rating: 65 kAIC at 240 Vac, 35 kAIC at 480 Vac
• Dimensions: 3.38 in (L) x 6 in (H) x 4.13 in (W)
• Weight: 4.5 lbs

Material Compliance and Certifications:

• Certifications: The Eaton FD3150 circuit breaker is UL listed, ensuring it meets stringent safety and performance standards.

Suitability:

• The FD3150 is ideally suited for use in commercial and industrial electrical systems where high performance and reliability are paramount. Its robust interrupting capacity makes it perfect for installations requiring protection against high fault currents, ensuring the safety and integrity of your electrical infrastructure.
