FD3125L 175A Circuit Breaker

FD3125L 175A Circuit Breaker

The Eaton FD3125L is a high-performance, Series C, molded case circuit breaker designed to provide reliable and efficient protection for electrical systems in commercial and industrial settings. With a robust 175A rating and a durable three-pole configuration, this breaker ensures optimal safety and functionality. Engineered with thermal magnetic trip technology, the FD3125L effectively safeguards circuits against overloads and short circuits, making it an essential component for maintaining system integrity and preventing electrical failures.

Key Features and Benefits

• High Amperage Rating: The 175A capacity makes it suitable for a wide range of heavy-duty applications, ensuring reliable performance even under high load conditions.
• Durable Construction: Designed with a sturdy molded case, the FD3125L offers enhanced durability and longevity, capable of withstanding the rigors of industrial environments.
• Thermal Magnetic Trip: This advanced trip mechanism provides precise protection by combining both thermal and magnetic elements to respond quickly to overloads and short circuits.
• Versatile Application: Ideal for commercial and industrial applications, the FD3125L can be used in various settings, from manufacturing plants to large office complexes, providing versatile protection solutions.

Technical Specifications

• Amperage Rating: 175A
• Voltage Rating: 600Vac, 250Vdc
• Interrupt Rating: 65kAIC at 240Vac, 35kAIC at 480Vac
• Number of Poles: Three-pole
• Dimensions: Length 3.38 in, Height 6 in, Width 4.13 in
• Weight: 4.5 lb
• Frequency Rating: 50 to 60 Hz
• Trip Type: Fixed thermal, fixed magnetic

Material Compliance and Certifications

• Certifications: UL Listed, ensuring compliance with stringent safety standards.
• Material Compliance: Constructed from high-quality materials that meet industry standards for safety and performance.

Suitability

• The Eaton FD3125L circuit breaker is perfectly suited for applications requiring high reliability and robust protection. Its high interrupting capacity makes it ideal for protecting heavy machinery and electrical systems in commercial and industrial facilities. The breaker’s three-pole design ensures comprehensive protection for three-phase electrical systems, making it an excellent choice for complex electrical networks.
