FD3125 125 Circuit Breaker

FD3125 125 Circuit Breaker

The Eaton FD3125 is a high-performance molded case circuit breaker from the acclaimed Series C range, designed to deliver reliable circuit protection in demanding applications. Engineered for superior performance, this three-pole breaker is rated at 125 A and can handle voltages up to 600 Vac and 250 Vdc. Its fixed thermal and magnetic trip features ensure consistent and precise protection against overloads and short circuits, making it an ideal choice for both industrial and commercial settings.

Key Features and Benefits:

• High Interrupting Capacity: The FD3125 offers a robust interrupting capacity of 65 kAIC at 240 Vac and 35 kAIC at 480 Vac, providing exceptional protection against electrical faults.
• Reliable Protection: With fixed thermal and magnetic trip settings, this breaker delivers accurate and reliable protection, reducing the risk of electrical damage and enhancing system safety.
• Versatile Application: Suitable for a wide range of applications, including motor protection, the FD3125 ensures reliable performance in both line and load terminals.
• Durability and Longevity: Built to Eaton's high standards, this circuit breaker is designed for long-term reliability, with a warranty of one year from the installation date or eighteen months from the shipment date, whichever comes first.

Technical Specifications:

• Amperage Rating: 125 A
• Voltage Rating: 600 Vac, 250 Vdc
• Interrupting Rating: 65 kAIC at 240 Vac, 35 kAIC at 480 Vac
• Trip Type: Fixed Thermal, Fixed Magnetic
• Frame Type: F-Frame
• Poles: 3
• Dimensions: 3.38 inches (Length/Depth) x 6 inches (Height) x 4.13 inches (Width)
• Weight: 4.5 lb

Material Compliance and Certifications:

• The Eaton FD3125 circuit breaker complies with the latest industry standards and certifications to ensure safety and performance. It is UL Listed, affirming its adherence to rigorous safety and quality standards. Eaton's commitment to compliance and certification ensures that this circuit breaker meets all necessary regulatory requirements, providing peace of mind and reliability in every installation.

Suitability:

• The FD3125 is suitable for various applications, particularly in industrial and commercial environments where high interrupting capacity and reliable protection are crucial. Its robust design and dependable performance make it an excellent choice for protecting electrical systems in manufacturing plants, commercial buildings, and other demanding settings. Whether used for motor protection or as part of a broader electrical protection strategy, the FD3125 delivers the reliability and peace of mind that professionals require.
