FD3090 - 90Amp Circuit Breaker

FD3090 - 90Amp Circuit Breaker

The Eaton FD3090 Series C Molded Case Circuit Breaker is a robust and reliable solution designed for demanding electrical distribution systems. Engineered to deliver superior performance and safety, this three-pole, 90A circuit breaker is ideal for a wide range of applications, including commercial, industrial, and residential settings. With a voltage rating of 600 VAC and 250 VDC, it provides exceptional protection for electrical circuits, ensuring seamless operation and safeguarding equipment from overloads and short circuits.

Key Features and Benefits:

• High Interrupting Capacity: The FD3090 boasts a high interrupting capacity of 35 kAIC at 480 VAC and 65 kAIC at 240 VAC, making it highly effective in mitigating potential electrical hazards and ensuring system reliability.
• Fixed Thermal and Magnetic Trip: This circuit breaker features a fixed thermal and magnetic trip unit, providing consistent and reliable protection against overloads and short circuits.
• Durable Construction: Built with high-quality materials, the FD3090 ensures long-lasting performance and durability, even in harsh environments.
• Ease of Installation: Designed for load-side connection and operating at frequencies of 50/60 Hz, the FD3090 is easy to install and integrate into existing electrical systems.

Technical Specifications:

• Amperage Rating: 90A
• Voltage Rating: 600 VAC, 250 VDC
• Interrupting Capacity: 35 kAIC at 480 VAC, 65 kAIC at 240 VAC
• Trip Type: Fixed thermal, fixed magnetic
• Number of Poles: Three-pole
• Frequency Rating: 50/60 Hz
• Dimensions: 3.38 in (L) x 6 in (H) x 4.13 in (W)
• Weight: 4.5 lb

Material Compliance and Certifications:

• Compliance: The Eaton FD3090 circuit breaker is UL Listed, ensuring it meets rigorous safety and performance standards. Eaton’s commitment to quality and reliability is backed by a comprehensive warranty, covering one year from the date of installation or eighteen months from the date of shipment, whichever comes first.

Suitability:

• Commercial Buildings: Ensuring reliable power distribution and protection in office buildings, retail stores, and other commercial facilities.
• Industrial Applications: Providing robust protection for manufacturing plants, warehouses, and other industrial environments where high interrupting capacity is crucial.
• Residential Complexes: Offering dependable protection for electrical circuits in large residential buildings and complexes.

The FD3090 is also suitable for applications requiring adherence to stringent safety standards and where equipment reliability is paramount. Whether for new installations or upgrades to existing systems, the Eaton FD3090 Series C Molded Case Circuit Breaker delivers unmatched performance and peace of mind.
