FD3060 60A Circuit Breaker

FD3060 60A Circuit Breaker

The Eaton FD3060 Series C molded case circuit breaker is a robust and dependable solution designed to ensure the safety and efficiency of your electrical systems. This three-pole, 60 A breaker operates at 600 VAC and 250 VDC, making it suitable for a wide range of applications, from industrial to commercial settings. The FD3060 features a fixed thermal and fixed magnetic trip type, ensuring precise and reliable protection against overcurrent and short circuits. Its load-side termination and compatibility with 50/60 Hz frequencies further enhance its versatility and performance. With an interrupt rating of 65 kAIC at 240 VAC and 35 kAIC at 480 VAC, this breaker is engineered to handle high fault currents, providing superior protection for your electrical infrastructure.

Key Features and Benefits:

• High Interrupt Rating: Capable of handling 65 kAIC at 240 VAC and 35 kAIC at 480 VAC, ensuring robust protection against high fault currents.
• Reliable Trip Mechanism: Fixed thermal and fixed magnetic trip types offer consistent and accurate response to overcurrent and short circuits.
• Versatile Application: Suitable for a variety of industrial and commercial applications, operating efficiently at 600 VAC and 250 VDC.

Technical Specifications:

• Amperage Rating: 60 A
• Voltage Rating: 600 VAC, 250 VDC
• Trip Type: Fixed thermal, fixed magnetic
• Interrupt Rating: 65 kAIC at 240 VAC, 35 kAIC at 480 VAC
• Frequency Rating: 50/60 Hz
• Number of Poles: Three-pole
• Dimensions: 3.38" (L) x 6" (H) x 4.13" (W)
• Weight: 4.5 lbs
• Termination: Load side

Material Compliance and Certifications:

• Compliance: The Eaton FD3060 circuit breaker is UL listed, ensuring it meets rigorous safety and performance standards. Eaton provides a warranty of one year from the date of installation or eighteen months from the date of shipment, whichever occurs first, under their Selling Policy 25-000.

Suitability:

• This circuit breaker is ideal for protecting electrical circuits in industrial and commercial environments, offering reliable performance and safety. Its high interrupting capacity makes it suitable for installations where high fault currents are anticipated, ensuring your electrical systems remain safeguarded against potential damages and operational disruptions.
