FD3030L - 30Amp Circuit Breaker

FD3030L - 30Amp Circuit Breaker

When your circuit breaker needs to be replaced, getting the specifications right matters. A breaker can appear to be the correct one at first glance and still have differences that affect compatibility. Frame style, trip characteristics, terminal arrangement, and interrupting capacity all need to match the equipment already in service.

The Eaton FD3030L is a 30 Amp, three-pole molded case circuit breaker from the Series C family, built with an F-frame design for compatible applications. It includes a T186 thermal magnetic trip unit that provides protection against overloads and short circuits while maintaining the original protection setup of the electrical system.

Key Features and Benefits

• Eaton Series C complete molded case circuit breaker
• Catalog Number: FD3030L
• 30 Amp current rating
• Three-pole configuration
• F-frame construction
• T186 thermal magnetic trip unit
• Rated for 600 VAC and 250 VDC applications
• Line and load terminal configuration
• Form, fit, and function replacement for compatible Eaton Series C equipment
• Suitable for maintenance programs and spare breaker inventory
• Built to last in commercial and industrial electrical systems


Technical Specifications

• Manufacturer: Eaton

• Catalog Number: FD3030L

• Series: Series C

• Product Type: Molded Case Circuit Breaker

• Circuit Breaker Type: FD

• Frame: F

• Frame Type: Complete Breaker

• Amperage Rating: 30 Amps

• Number of Poles: 3

• Trip Unit: T186 Thermal Magnetic

• Voltage Rating: 600 VAC / 250 VDC

• Frequency: 50/60 Hz

• Interrupting Rating:
  • 65 kAIC at 240 VAC
  • 35 kAIC at 480 VAC
• Terminals: Line and Load

• Dimensions: 6 in. H × 4.13 in. W × 3.38 in. D

• Weight: 4.5 lbs


Material Compliance and Certifications

The Eaton FD3030L is UL Listed and manufactured to published specifications for Series C molded case circuit breakers. Before installation, confirm the replacement breaker matches the existing equipment, including the frame size, amperage rating, number of poles, voltage rating, interrupting capacity, trip unit, and terminal configuration.

Where It Works Best

The FD3030L is commonly used in manufacturing plants, commercial buildings, warehouses, schools, healthcare facilities, municipal facilities, and industrial operations that use compatible Eaton Series C F-frame equipment.
