FD3025L - 25Amp Circuit Breaker

FD3025L - 25Amp Circuit Breaker

There's a reason experienced maintenance teams spend extra time checking every number on a circuit breaker before swapping it out. Two breakers may look nearly identical on the outside, but differences in terminal configuration, interrupting rating, or trip characteristics can affect how the entire electrical system operates. Matching your original specifications helps preserve the protection built into the equipment and can save you valuable troubleshooting time later.

The Eaton FD3025L Series C molded case circuit breaker is a 25 Amp, three-pole replacement breaker intended for compatible Series C F-frame electrical distribution systems. It uses a T186 thermal magnetic trip unit to respond to overloads and short circuits while maintaining the original form, fit, and function of the installation.

Key Features and Benefits

• Eaton Series C complete molded case circuit breaker
• Catalog Number: FD3025L
• 25 Amp continuous current rating
• Three-pole configuration
• F-frame construction
• T186 thermal magnetic trip unit
• Rated for 600 VAC and 250 VDC
• Line and load terminal configuration
• Interrupting ratings:
  • 65 kAIC at 240 VAC
  • 35 kAIC at 480 VAC
• Form, fit, and function replacement for compatible Eaton Series C equipment
• Well suited for preventive maintenance programs and spare breaker inventory
• Built to last for long-term service in commercial and industrial environments


Technical Specifications

• Manufacturer: Eaton

• Catalog Number: FD3025L

• Series: Series C

• Product Type: Molded Case Circuit Breaker

• Circuit Breaker Type: FD

• Frame: F

• Frame Type: Complete Breaker

• Amperage Rating: 25 Amps

• Number of Poles: 3

• Trip Unit: T186 Thermal Magnetic

• Voltage Rating: 600 VAC / 250 VDC

• Frequency: 50/60 Hz

• Interrupting Rating:
  • 65 kAIC at 240 VAC
  • 35 kAIC at 480 VAC
• Terminal Configuration: Line and Load

• Dimensions: 6 in. H × 4.13 in. W × 3.38 in. D

• Weight: 4.5 lbs


Material Compliance and Certifications

The Eaton FD3025L is UL Listed and manufactured to published specifications for Series C molded case circuit breakers. Before installation, verify the frame size, amperage, number of poles, voltage rating, interrupting capacity, trip unit, and terminal configuration to ensure compatibility with the existing electrical system.

Where It Works Best

The FD3025L is commonly used in commercial buildings, manufacturing facilities, warehouses, healthcare facilities, educational campuses, municipal buildings, and industrial plants that utilize compatible Eaton Series C F-frame equipment.
