Electrical rooms have a way of reminding you that appearances can be deceiving. It's not unusual to find two breakers that look almost identical sitting side by side, yet one small difference in the trip unit or interrupting rating can make all the difference during installation. That's why experienced maintenance teams spend just as much time confirming the catalog number and electrical ratings as they do pulling the old breaker out of the panel.

The Eaton FD3020L Series C molded case circuit breaker is a 20 Amp, three-pole replacement breaker for compatible F-frame Series C applications. It uses a T186 thermal magnetic trip unit to respond to overloads and short circuits while maintaining the protection the original equipment was built around.

Key Features and Benefits

• Eaton Series C complete molded case circuit breaker
• Catalog Number: FD3020L
• 20 Amp continuous current rating
• Three-pole configuration
• F-frame construction
• T186 thermal magnetic trip unit
• Rated for 600 VAC and 250 VDC applications
• Line and load terminal configuration
• Interrupting ratings:
  • 65 kAIC at 240 VAC
  • 35 kAIC at 480 VAC
• Form, fit, and function replacement for compatible Eaton Series C equipment


Technical Specifications

• Manufacturer: Eaton

• Catalog Number: FD3020L

• Series: Series C

• Product Type: Molded Case Circuit Breaker

• Circuit Breaker Type: FD

• Frame: F

• Frame Type: Complete Breaker

• Amperage Rating: 20 Amps

• Number of Poles: 3

• Trip Unit: T186 Thermal Magnetic

• Voltage Rating: 600 VAC / 250 VDC

• Frequency: 50/60 Hz

• Interrupting Rating:
  • 65 kAIC at 240 VAC
  • 35 kAIC at 480 VAC
• Terminals: Line and Load

• Dimensions: 6 in. H × 4.13 in. W × 3.38 in. D

• Weight: 4.5 lbs


Material Compliance and Certifications

The Eaton FD3020L is UL Listed and manufactured to published specifications for Series C molded case circuit breakers. Before installing any replacement breaker, verify the frame size, amperage, number of poles, voltage rating, interrupting capacity, trip unit, and terminal configuration to ensure compatibility with the existing equipment.

Where It Works Best

The FD3020L is commonly used in manufacturing plants, commercial buildings, schools, healthcare facilities, warehouses, municipal properties, and industrial facilities that utilize compatible Eaton Series C F-frame distribution equipment.
