FD3015L - 15Amp Circuit Breaker

FD3015L - 15Amp Circuit Breaker

When your breaker needs to be replaced, matching the original specifications is what matters. A replacement that fits correctly and carries the same electrical ratings helps keep existing equipment operating the way it was intended. That's exactly where the Eaton FD3015L fits in. This 15 Amp, 3-pole molded case circuit breaker is part of Eaton's trusted Series C family and uses the F-frame design with a T186 thermal magnetic trip unit to protect electrical circuits from overloads and short circuits.

Key Features and Benefits

• Eaton Series C complete molded case circuit breaker
• Catalog Number: FD3015L
• 15 Amp current rating
• Three-pole configuration
• F-frame construction
• T186 thermal magnetic trip unit
• Rated for 600 VAC and 250 VDC systems
• 50/60 Hz frequency rating
• Line and load terminals
• Form, fit, and function replacement for compatible Eaton equipment
• Helps support preventive maintenance programs and spare parts inventory
• Built to last in demanding commercial and industrial environments


Technical Specifications

• Manufacturer: Eaton

• Catalog Number: FD3015L

• Series: Series C

• Product Type: Molded Case Circuit Breaker

• Breaker Type: FD

• Frame: F

• Frame Type: Complete Breaker

• Amperage: 15 Amps

• Poles: 3

• Trip Unit: T186 Thermal Magnetic

• Voltage Rating: 600 VAC / 250 VDC

• Frequency: 50/60 Hz

• Interrupting Rating:65 kAIC @ 240 VAC
  • 35 kAIC @ 480 VAC
• Terminals: Line and Load

• Dimensions: 6 in. H × 4.13 in. W × 3.38 in. D

• Weight: 4.45 lbs


Material Compliance and Certifications

The Eaton FD3015L is UL Listed and manufactured to published specifications for Series C molded case circuit breakers. Before installation, verify the frame size, amperage, pole count, voltage rating, interrupting capacity, trip unit, and terminal configuration to ensure compatibility with the existing electrical equipment.

Where It Works Best

The FD3015L is commonly used in manufacturing facilities, commercial buildings, schools, healthcare facilities, warehouses, municipal buildings, and industrial plants where compatible Eaton Series C F-frame breakers are installed. It's well suited for replacing an existing breaker during scheduled maintenance, restoring service after a breaker has reached the end of its service life, or maintaining spare inventory for critical electrical systems.
