FD3015 - 15Amp Circuit Breaker

FD3015 - 15Amp Circuit Breaker

Finding the correct replacement circuit breaker starts with matching the original electrical specifications. A breaker may fit physically into the equipment, but differences in trip characteristics, interrupting ratings, or pole configuration can create unnecessary complications. The Eaton FD3015 is a 15 Amp, 3-pole Series C molded case circuit breaker built on Eaton's F-frame platform and intended as a form, fit, and function replacement for compatible electrical distribution systems. Equipped with a T186 thermal magnetic trip unit, it helps protect your connected equipment from overloads and short circuits while maintaining the protection scheme originally specified for the installation.

Key Features and Benefits

• Eaton Series C complete molded case circuit breaker
• Catalog Number FD3015
• 15 Amp current rating
• Three-pole configuration
• F-frame construction
• T186 thermal magnetic trip unit for overload and short-circuit protection
• Rated for systems up to 600 VAC and 250 VDC
• 50/60 Hz frequency rating
• Load-side terminals
• Interrupting rating of 65 kAIC at 240 VAC
• Interrupting rating of 35 kAIC at 480 VAC
• Form, fit, and function replacement for compatible Eaton Series C electrical equipment
• Built to last for commercial and industrial service applications


Technical Specifications

• Manufacturer: Eaton

• Catalog Number: FD3015

• Product Type: Molded Case Circuit Breaker

• Series: Series C

• Circuit Breaker Type: FD

• Frame: F

• Frame Type: Complete Breaker

• Amperage Rating: 15 Amps

• Poles: 3

• Trip Unit: T186 Thermal Magnetic

• Voltage Rating: 600 VAC / 250 VDC

• Frequency: 50/60 Hz

• Interrupting Rating:
  • 65 kAIC @ 240 VAC
  • 35 kAIC @ 480 VAC
• Terminals: Load Side

• Dimensions: 6 in. H × 4.13 in. W × 3.38 in. D

• Weight: 4.5 lbs


Material Compliance and Certifications

The Eaton FD3015 is UL Listed and manufactured to published specifications for Series C molded case circuit breakers. Before installation, verify the frame size, amperage, number of poles, voltage rating, interrupting capacity, trip unit, and terminal configuration to ensure compatibility with the existing electrical equipment. Small differences between similar breaker models can affect proper application, so confirming the details before installation is always a worthwhile step.

Where It Works Best

The FD3015 is commonly used in commercial facilities, manufacturing plants, industrial operations, schools, healthcare campuses, municipal buildings, warehouses, and other facilities utilizing compatible Eaton Series C F-frame electrical distribution equipment. It is well suited for replacing an existing breaker during scheduled maintenance, restoring service after an unexpected breaker failure, or maintaining spare inventory to reduce downtime.
