FD1030L - 30Amp Circuit Breaker

FD1030L - 30Amp Circuit Breaker

When you're replacing a breaker during scheduled maintenance or restoring a circuit after an unexpected failure, using a replacement that matches the original electrical specifications is essential. The FD1030L Eaton Series C molded case circuit breaker is a 30 Amp, single-pole complete breaker built for compatible Series C F-frame applications in commercial and industrial electrical systems. Equipped with a T186 thermal magnetic trip unit, it responds to overloads and short circuits while maintaining the published ratings required for many existing installations.

Key Features and Benefits

• Eaton Series C complete molded case circuit breaker
• 30 Amp current rating
• Single-pole configuration
• F-frame construction for compatible Series C equipment
• T186 thermal magnetic trip unit for overload and short-circuit protection
• Rated for 347 VAC and 125 VDC applications
• Line and load terminal configuration for installation flexibility
• 50/60 Hz frequency rating
• Form, fit, and function replacement for compatible electrical systems
• Well suited for preventive maintenance, repairs, and maintaining spare breaker inventory
• Built to last for demanding commercial and industrial environments


Technical Specifications

• Catalog Number: FD1030L

• UPC: 786685981000

• Series: Series C

• Product Type: Molded Case Circuit Breaker

• Circuit Breaker Type: FD

• Circuit Breaker Frame Type: Complete Breaker

• Frame: F

• Trip Unit: T186 Thermal Magnetic

• Amperage Rating: 30 Amps

• Number of Poles: Single-Pole

• Voltage Rating: 347 VAC, 125 VDC

• Frequency Rating: 50/60 Hz

• Interrupting Ratings:
  • 35 kAIC at 277 VAC
  • 18 kAIC at 347 VAC
• Terminals: Line and Load

• Height: 6.00 in.

• Width: 1.38 in.

• Depth: 3.38 in.

• Approximate Shipping Weight: 1.4 lbs.


Material Compliance and Certifications

The FD1030L is UL Listed and manufactured to the published electrical ratings for this catalog number. Before installation, confirm that the frame size, amperage, pole configuration, voltage rating, interrupting capacity, and terminal arrangement match the requirements of the existing equipment. Installation should always follow applicable electrical codes and be performed by qualified personnel.

Where It Works Best

The FD1030L is commonly used in commercial facilities, manufacturing plants, institutional buildings, healthcare environments, schools, and municipal properties that utilize compatible Eaton Series C electrical distribution equipment. It's a practical choice for replacing an existing breaker with matching specifications, supporting preventive maintenance programs, or keeping critical spare parts on hand to minimize downtime.
