FD1015 - 15Amp Circuit Breaker

FD1015 - 15Amp Circuit Breaker

When your circuit breaker needs to be replaced, matching the original specifications is what keeps the job moving. Amperage is only one piece of the puzzle. Frame size, voltage rating, interrupting capacity, and trip characteristics all need to line up with the equipment already in service. That's why maintenance professionals often look for a replacement that matches the original breaker as closely as possible.

The FD1015 is a 15 Amp, single-pole Series C molded case circuit breaker built for use in commercial and industrial electrical systems. It features an F-frame construction with a T186 thermal magnetic trip unit, combining overload and short-circuit protection in one compact breaker.

Key Features and Benefits

• 15 Amp current rating for branch circuit protection
• Single-pole configuration for compatible electrical systems
• Series C molded case circuit breaker with F-frame construction
• Thermal magnetic T186 trip unit protects against overloads and short circuits
• Rated for 347 VAC and 125 VDC applications
• Interrupting ratings of 35 kAIC at 277 VAC and 18 kAIC at 347 VAC
• Compact footprint for equipment designed around the F-frame platform
• Built to last in demanding commercial and industrial environments


Technical Specifications

• Catalog Number: FD1015

• Series: Series C

• Circuit Breaker Type: FD

• Product Type: Complete Molded Case Circuit Breaker

• Frame: F

• Frame Type: Complete Breaker

• Trip Type: T186

• Amperage Rating: 15 Amps

• Number of Poles: 1

• Voltage Rating: 347 VAC, 125 VDC

• Frequency: 50/60 Hz

• Interrupting Rating:35 kAIC @ 277 VAC
  • 18 kAIC @ 347 VAC
• Terminals: Load Side

• Dimensions: 6.00" H × 1.38" W × 3.38" D
  • Height: 6.00"
  • Width: 1.38"
  • Depth: 3.38"
• Approximate Shipping Weight: 1.65 lbs.


Material Compliance and Certifications

The FD1015 is UL Listed, meeting recognized safety standards for molded case circuit breakers. Before installation, verify that the electrical ratings, frame size, trip unit, pole configuration, and interrupting capacity match the equipment manufacturer's requirements and the application. Installation should always be completed in accordance with applicable electrical codes.

Where It Works Best

The FD1015 is commonly used in commercial buildings, manufacturing facilities, institutional properties, and other locations that continue to operate equipment built around Series C F-frame circuit breakers. It's a practical choice for replacing an existing breaker during routine maintenance, troubleshooting an electrical fault, or restoring service after a breaker has reached the end of its useful life.
