FCSCS364 w/ Mounting Kit - 200Amp Panelboard Switch

FCSCS364 w/ Mounting Kit - 200Amp Panelboard Switch

The Challenger FCSCS364 panelboard switch with mounting kit is built for demanding electrical jobs where safety and consistency matter. It’s rated for 200 amps at 600 volts A.C., making it a solid choice for commercial buildings, industrial facilities, and utility setups. The bolt-in connection keeps things tight and secure, helping reduce vibration problems that often show up over time. To save you some hassle, this unit also comes with a mounting strap kit, so you can get it installed without extra parts. It works with Class RK1 and RK5 fuses, giving you dependable overcurrent protection while keeping maintenance straightforward.

Key Features and Benefits

• Accepts Class RK1 and RK5 fuses: For strong circuit protection.
• Bolt-in mounting: Keeps connections secure and steady.
• Includes a strap kit: To make installation quicker and easier.
• Built tough: For long service life in commercial and industrial environments.

Technical Specifications

• Frame Type: FCSCS
• Voltage Rating: 600 Volts A.C.
• Amperage: 200 A
• Poles: 3
• Dimensions:
  • Width: 18.00 inches
  • Height: 8.25 inches
  • Depth: 7.00 inches
• Fuse Compatibility: Class RK1 and RK5
• Mounting: Bolt-in with included strap kit

Material Compliance and Certifications

• UL Listed: Meets strict safety requirements.
• RoHS Compliant: Made without restricted or harmful materials.
• ISO 9001 Certified: Manufactured under recognized quality standards.

Where It Works Best

• Commercial properties – Offices, retail stores, and multi-unit spaces.
• Industrial plants – Handles the heavy electrical loads from machinery and production lines.
• Critical sites – Data centers, hospitals, and utilities that need dependable uptime.
