GENERAL ELECTRIC

FBV36TE080RV - 80Amp Circuit Breaker

FBV36TE080RV - 80Amp Circuit Breaker

Regular price $0.00 USD
Regular price Sale price $0.00 USD
Sale Sold out
Shipping calculated at checkout.
Condition

FBV36TE080RV - 80Amp Circuit Breaker

Unlock unparalleled protection and performance with the FBV36TE080RV - 80A MCCB 3P 600Y347, a top-tier molded case circuit breaker that brings together innovative design and exceptional functionality. This product is engineered by leveraging advanced materials and double-break rotary contact structures, enhancing its interruption capabilities to meet demanding electrical standards.

Key Features and Benefits:

  • High Interruption Capacity: Capable of handling fault currents up to 150kA at 480VAC, ensuring reliable protection against electrical faults.
  • Selective Coordination and Arc Flash Reduction: Minimizes downtime and enhances safety by selectively isolating faults and reducing arc flash energy.
  • Current Limitation: Offers superior protection by limiting the let-through current under fault conditions, thereby protecting downstream equipment.
  • Thermal Magnetic Trip Technology: Comes with a factory-installed non-user interchangeable thermal-magnetic trip unit, ensuring precise operation.

Technical Specifications:

  • Poles: 3
  • Amperage: 80 A
  • System Voltage: Up to 600/347 Vac
  • Interrupting Ratings: 65 kAIC at 240 Vac, 35 kAIC at 480 Vac, and 22 kAIC at 600/347 Vac
  • Trip Function: LI (Long-Time and Instantaneous)

Material Compliance and Certifications:

  • UL Listed: Ensures compliance with rigorous electrical standards (UL File Number E11592).

Suitability:

  • Reverse Feed: Suitable for reverse feed use, offering flexible installation options.
  • Compatibility: Specifically designed for General Electric type AD panels, with load lugs and line connections included (RV suffix).

Designed to meet the needs of both commercial and industrial applications, the FBV36TE080RV circuit breaker is an ideal solution for enhancing system reliability and protection. Its robust design and compliance with UL standards make it a reliable choice for safeguarding electrical installations.
