FBV36TE070RV - 70Amp Circuit Breaker

FBV36TE070RV - 70Amp Circuit Breaker

Experience superior protection and operational excellence with the FBV36TE070RV, a top-tier molded case circuit breaker (MCCB) designed for robust performance and reliability. Ideal for use in demanding industrial environments, this 3-pole breaker ensures safe operation with its high interrupting ratings and advanced features tailored for efficiency and safety.

Key Features and Benefits:

• High Interrupting Capacity: Equipped with a remarkable interrupting rating of up to 200kA at 480 VAC, this circuit breaker is designed to handle high fault conditions, ensuring safety and system integrity.
• Selective Coordination and Arc Flash Reduction: The breaker's selective coordination minimizes downtime by isolating faults only to the affected circuit without impacting other areas. It also significantly reduces arc flash energy, enhancing personnel safety.
• Current Limitation: With its ability to limit the current flow during a fault, the FBV36TE070RV minimizes thermal and mechanical stresses on equipment, extending the lifespan of your electrical system.
• Versatile Installation Options: Available with or without load lugs, and specifically designed connections for General Electric type AD panels, installation is streamlined and adaptable to various setups.

Technical Specifications:

• Amperage: 70 A
• Poles: 3
• System Voltage: Up to 600/347 VAC
• Trip Function: LI (Long-Time and Instantaneous)
• Frame Type: FB 100
• Interrupting Ratings: 65 KAIC at 240 VAC, 35 KAIC at 480 VAC, and 22 KAIC at 600/347 VAC
• Lugs: FCALK14, suitable for wire sizes 4-1/0 AWG

Material Compliance and Certifications:

• UL Listed: Ensures compliance with rigorous safety standards (UL file number E11592).
• HACR Rated: Suitable for heating, air-conditioning, and refrigeration equipment, meeting industry-specific safety and performance requirements.

Suitability:

• Versatile Application: Perfect for industrial, commercial, and construction environments where high reliability and performance are paramount.
• Suitable for Reverse Feed: Allows for flexible installation and application.

Crafted using cutting-edge technology and materials, the FBV36TE070RV offers a reliable solution for protecting electrical systems from overloads and short circuits. Its robust design and compliance with safety standards make it an essential component for modern electrical infrastructures.
