FBV36TE060RV - 60Amp Circuit Breaker

FBV36TE060RV - 60Amp Circuit Breaker

Discover the ultimate solution in circuit protection with our FBV36TE060RV molded case circuit breaker, part of the advanced Record Plus product line. Designed for both reliability and performance, the FBV36TE060RV offers an exceptional 60 ampere, 3-pole protection suitable for systems up to 600Y/347 volts. This circuit breaker integrates innovative features such as double-break rotary contact structures and advanced ablative materials that enhance interruption capabilities, enabling it to handle fault current ratings up to 200kA.

Key Features and Benefits:

• Advanced Protection: Utilizes a thermal-magnetic trip function that reliably safeguards against overcurrent, ensuring robust protection with ratings up to 150kA at 480VAC.
• Selective Coordination: Minimizes system downtime by isolating faults without affecting the entire system.
• Arc Flash Reduction: Designed to limit arc flash energy, enhancing safety for equipment and personnel.
• Versatile Installation: Available with or without load lugs, the RV model includes line connections specially designed for General Electric type AD panels, supporting flexible installation options.

Technical Specifications:

• Amperage: 60A
• Poles: 3
• System Voltage: 600/347 Vac
• Interrupting Ratings: 65 KAIC at 240 Vac, 35 KAIC at 480 Vac, 22 KAIC at 600/347 Vac
• Trip Unit: Factory installed non-user interchangeable, fixed LI function

Material Compliance and Certifications:

• UL Listed: Ensures compliance with the highest safety standards (UL file number E11592).
• No Special Markings: Standard HACR rated.

Suitability:

• Commercial and Industrial Applications: Ideal for environments demanding high reliability and safety.
• Suitable for Reverse Feed: Allows flexibility in system design.

Designed for longevity and safety, the FBV36TE060RV is an exemplary choice for commercial and industrial applications where robust circuit protection is paramount.
