FAL360201021 - 20 Amp Circuit Breaker

FAL360201021 - 20 Amp Circuit Breaker

Electrical systems that incorporate remote shutdown functions depend on having the right breaker in place. The FAL360201021 is a 20 Amp, 3-pole thermal magnetic circuit breaker with a factory-installed shunt trip, built for compatible FAL applications operating on systems rated up to 600VAC. When it's time to replace an existing breaker, matching the original configuration helps you avoid unnecessary changes to the panel, wiring, or control circuit.

The integrated shunt trip allows the breaker to open from a remote electrical signal, a feature often found in equipment tied into emergency stop stations, fire alarm systems, or other building controls. Beyond that, it functions just as you'd expect from a thermal magnetic breaker—handling sustained overloads with its thermal element while responding quickly to short-circuit conditions through magnetic tripping. Its three-pole, unit-mounted design makes it a natural fit anywhere a compatible FAL breaker is already installed.

Key Features and Benefits

• 20 Amp current rating
• Three-pole construction for three-phase power distribution
• Factory-installed shunt trip for remote breaker opening
• Thermal magnetic trip unit provides overload and short-circuit protection
• Rated for electrical systems up to 600VAC
• Unit-mount configuration
• Line and load lug connections
• HACR rated for approved HVAC and refrigeration equipment
• Preserves the original form, fit, and function of compatible FAL installations
• Built to last for everyday commercial and industrial service

Technical Specifications

• Catalog Number: FAL360201021

• Product Type: Thermal Magnetic Circuit Breaker with Factory Shunt Trip

• Series: FAL

• Current Rating: 20 Amps

• Voltage Rating: 600VAC

• Number of Poles: 3

• Trip Unit Technology: Thermal Magnetic

• Mounting Style: Unit Mount

• Breaking Capacity Code: A

• Magnetic Hold Current: 275 Amps

• Magnetic Trip Current: 600 Amps

• Electrical Connections:
  • Line Lugs
  • Load Lugs
• Terminal Identifier: AL50FA

• Phase Connection: ABC

• Dimensions:
  • Height: 6.40 in. H
  • Width: 4.50 in. W
  • Depth: 4.13 in. D
• Country of Origin: Mexico


Material Compliance and Certifications

The FAL360201021 carries UL Listing and CSA Certification and is HACR rated for approved heating, air conditioning, and refrigeration applications. Before replacing an existing breaker, verify that the catalog number, electrical ratings, shunt trip configuration, and installation requirements match the original equipment.

Where It Works Best

This breaker is frequently found in commercial and industrial facilities where remote tripping is part of the original electrical design. Typical applications include switchboards, panelboards, motor control equipment, HVAC systems, pumping equipment, compressors, conveyors, and manufacturing machinery connected to emergency shutdown or building control systems.
