FAL360151021 - 15 Amp Circuit Breaker

FAL360151021 - 15 Amp Circuit Breaker

When your electrical system calls for a 15 Amp, 3-pole circuit breaker with remote tripping capability, the FAL360151021 is designed to match the form, fit, and function of compatible FAL-series installations. Rated for 600VAC, this thermal-magnetic breaker combines overload and short-circuit protection with a factory-installed shunt trip that allows the breaker to be opened remotely via an external control circuit. It's a practical choice for maintaining existing commercial and industrial equipment without changing the original panel layout or breaker configuration.

The thermal element responds to sustained overload conditions, while the magnetic trip reacts to higher fault currents, helping protect connected equipment during everyday operation. With line and load lug connections and a unit-mount design, the FAL360151021 installs into systems built for the FAL frame.

Key Features and Benefits

• 15 Amp current rating
• Three-pole configuration for three-phase systems
• Factory-installed shunt trip for remote opening
• Thermal magnetic trip unit protects against overloads and short circuits
• Rated for use on systems up to 600VAC
• Unit-mount FAL frame design
• Line and load lug terminations
• HACR rated for qualifying HVAC and refrigeration equipment
• Designed as a form, fit, and functional replacement for compatible FAL-series installations
• Built to last for long-term use in commercial and industrial environments

Technical Specifications

• Catalog Number: FAL360151021

• Product Type: Circuit Breaker

• Series: FAL

• Trip Unit Technology: Thermal Magnetic

• Current Rating: 15 Amps

• Voltage Rating: 600VAC

• Number of Poles: 3

• Breaking Capacity Code: A

• Mounting Style: Unit Mount

• Shunt Trip: Factory Installed

• Electrical Connections:
  • Line Lugs
  • Load Lugs
• Terminal Identifier: AL50FA

• Phase Connection: ABC

• Magnetic Hold Current: 275 Amps

• Magnetic Tripping Current: 600 Amps

• Application Rating: HACR

• Dimensions: 6.40 in. H × 4.50 in. W × 4.13 in. D

• Country of Origin: Mexico


Material Compliance and Certifications

The FAL360151021 is UL Listed and CSA Certified for use in compatible electrical applications. It is intended as a form-, fit-, and function-replacement for existing FAL-series equipment. Installation should always be completed by qualified personnel in accordance with the National Electrical Code (NEC), local regulations, and the equipment manufacturer's instructions.

Where It Works Best

• Commercial buildings
• Industrial facilities
• Manufacturing equipment
• Three-phase electrical distribution systems
• HVAC and refrigeration equipment requiring HACR-rated protection
• Control panels with remote trip functions
• Emergency shutdown circuits
• Existing FAL-series electrical systems requiring a compatible replacement
