FAL340601021 - 60 Amp Circuit Breaker

FAL340601021 - 60 Amp Circuit Breaker

When you're replacing a circuit breaker in an existing electrical system, matching the original catalog number and factory-installed accessories can save time and help maintain the equipment's intended configuration. The Square D FAL340601021 is a 60 Amp, 3-pole FA Series molded case circuit breaker with a factory-installed shunt trip, making it a suitable replacement for compatible 480 VAC applications that require remote tripping capability. Its thermal-magnetic trip unit combines two levels of protection: the thermal element responds to prolonged overload conditions, while the magnetic element reacts almost instantly to short circuits.

Key Features and Benefits

• 60 Amp current rating
• Three-pole FA Series molded case circuit breaker
• Factory-installed shunt trip for remote trip operation
• Thermal-magnetic trip unit protects against overloads and short circuits
• 480 VAC voltage rating
• Unit-mount construction
• Line and load lug connections
• AL100FA terminal configuration
• HACR rated for qualifying heating, ventilation, air conditioning, and refrigeration equipment

Technical Specifications

• Manufacturer: Square D

• Catalog Number: FAL340601021

• Series: FA

• Product Type: Molded Case Circuit Breaker with Factory-Installed Shunt Trip

• Current Rating: 60 Amps

• Number of Poles: 3

• Voltage Class: 480 VAC

• Trip Unit Technology: Thermal-Magnetic

• Breaking Capacity Code: A

• Mounting Mode: Unit Mount

• Electrical Connections:
  • Line Lugs
  • Load Lugs
• Terminal Identifier: AL100FA

• Phase Connection: ABC

• Magnetic Hold Current: 800 A

• Magnetic Tripping Current: 1450 A

• Circuit Breaker Application: HACR Rated

• Dimensions:
  • Height: 6.4 in.
  • Width: 4.5 in.
  • Depth: 4.13 in.

Material Compliance and Certifications

The Square D FAL340601021 is UL Listed and CSA Certified for applicable molded case circuit breaker installations. It is also HACR rated for qualifying HVAC and refrigeration applications. Always verify that the amp rating, pole configuration, voltage class, mounting style, terminal connections, and factory-installed shunt trip match the requirements of the equipment being serviced. Install according to the National Electrical Code (NEC) and applicable local codes.

Where It Works Best

• Commercial electrical distribution panels
• Industrial switchboards and panelboards
• Manufacturing facilities
• HVAC and refrigeration equipment
• Three-phase branch circuits
• Equipment requiring remote shunt trip operation
• Maintenance and replacement of compatible 480 VAC FA Series installations
