FAL24070 - 70 Amp Circuit Breaker

FAL24070 - 70 Amp Circuit Breaker

Discover dependable circuit protection with the FAL24070 70 A circuit breaker — designed to safeguard electrical systems in industrial, commercial and HVAC installations with confidence and clarity. From its thermal-magnetic trip unit to its high fault-current capability, this breaker delivers reliable performance when it matters most.

Key Features and Benefits

• Thermal-magnetic trip unit: Combines overload protection (thermal) and instantaneous short-circuit interruption (magnetic), so you get responsive protection against both slow and fast faults.
• High interrupting capacity: Rated to handle fault currents up to 1,450 A at the 70 A rating — making it capable of standing up to demanding applications without compromise.
• Compact size: With a height of 6.4″, width of 3″ and depth of 4.13″, the breaker is sized to fit in standard panel boards, helping you save space and simplify installation.
• HACR-rated: Approved for heating, air-conditioning and refrigeration systems — a versatile choice across HVAC and commercial power applications.
• Green Premium label: Indicates compliance with RoHS and REACh environmental standards, reflecting a commitment to sustainability and reduced environmental impact.


Technical Specifications

• Voltage rating: 480 V

• Current rating: 70 A

• Number of poles: 2

• Breaking capacity code: A

• Magnetic hold current: 800 A

• Magnetic tripping current: 1,450 A

• Mounting mode: Unit mount

• Electrical connections: Lugs for both line and load terminals

• Dimensions:
  • Height: 6.4″
  • Width: 3″
  • Depth: 4.13″
• Weight: 3.53 lbs (1.601 kg)

• Certifications: UL Listed, CSA


Material Compliance and Certifications

• Environmental Standards: The FAL24070 meets rigorous environmental and safety standards. It carries the Green Premium® label signifying adherence to RoHS and REACh regulations, is mercury-free, and aligns with global eco-labelling guidelines.
• Certifications: Certified by UL and CSA, this breaker affirms both performance and regulatory peace of mind.


Where It Works Best

• This breaker is ideal for industrial and commercial electrical systems where dependable protection against overloads and short circuits is critical. Use it in panelboards servicing HVAC equipment, manufacturing lines, or any facility requiring a 70 A rated, 480 V capable unit with high fault-current rating and space-efficient installation. If you’re specifying protection for an HVAC system, compressor feed, motor starter panel or general-purpose branch circuit in a commercial facility, this is a sensible and reliable option.
