FAL24015 - 15 Amp Circuit Breaker

FAL24015 - 15 Amp Circuit Breaker

Finding the correct replacement breaker is often about matching the details that keep your existing electrical system working as intended. The FAL24015 is a 15 Amp, 2-pole FA Series thermal-magnetic molded case circuit breaker designed for compatible electrical equipment where the original breaker specifications need to be maintained.

The FAL24015 also carries a HACR rating, making it suitable for qualifying heating, ventilation, air conditioning, and refrigeration applications. It includes line and load lug connections and features a compact molded case design built for long-term service. Built to last, this breaker helps maintain the original form, fit, and function of compatible installations without changing your existing equipment configuration.

Key Features and Benefits

• 15 Amp current rating
• Two-pole design for compatible electrical systems
• FA Series thermal-magnetic molded case circuit breaker
• Thermal protection helps respond to overload conditions
• Magnetic protection helps respond to short-circuit events
• HACR rated for qualifying HVAC and refrigeration applications
• Unit-mount installation style
• Includes line and load lug connections
• Compact molded case construction built for long-term service
• UL Listed and CSA certified
• Maintains the original form, fit, and function required for compatible FA Series applications

Technical Specifications

• Catalog Number: FAL24015

• Product Type: Circuit Breaker

• Series: FA

• Trip Unit Technology: Thermal-Magnetic

• Current Rating: 15 Amps

• Number of Poles: 2 Poles

• Mounting Mode: Unit Mount

• Breaking Capacity Code: A

• Circuit Breaker Application: HACR Rated

• Electrical Connections:
  • Line Lugs
  • Load Lugs
• Terminal Identifier: AL50FA

• Magnetic Hold Current: 275A

• Magnetic Tripping Current: 600A

• Dimensions:
  • Height: 6.4 inches
  • Width: 3 inches
  • Depth: 4.13 inches

Material Compliance and Certifications

The FAL24015 is a thermal-magnetic molded case circuit breaker with UL Listed and CSA certifications. It is intended for compatible FA Series electrical equipment in which the amperage, pole configuration, mounting style, and application requirements match those of the existing installation. Before installation, confirm that the breaker specifications align with the electrical system requirements. Installation should be performed by qualified electrical personnel following the National Electrical Code (NEC), applicable local electrical codes, and equipment requirements.

Where It Works Best

• Compatible FA Series electrical distribution equipment
• Commercial electrical panels
• Industrial electrical systems
• HVAC and refrigeration applications requiring HACR-rated protection
• Two-pole branch circuit applications
• Electrical maintenance and repair projects
• Existing installations requiring a compatible 15 Amp, 2-pole FA Series breaker
