FA24030AC **Old Style** - 30 Amp Circuit Breaker

FA24030AC **Old Style** - 30 Amp Circuit Breaker

If you're maintaining an existing FA-frame electrical distribution system, the FA24030AC Old Style offers the form, fit, and function needed for a compatible replacement. This 30 Amp, 2-pole molded case circuit breaker uses a thermal-magnetic trip mechanism to help protect electrical circuits from overloads and short circuits during everyday operation. Built for I-Line plug-in installations with an A-C phase configuration, it is well-suited to applications where matching the original equipment is essential.

Key Features and Benefits

• 30 Amp current rating
• Two-pole molded case circuit breaker
• FA frame, Old Style configuration
• Thermal-magnetic trip mechanism for overload and short-circuit protection
• I-Line plug-in mounting design
• A-C phase configuration
• Interrupting rating of 14kA at 480VAC and 18kA at 240VAC
• HACR Type rated
• Designed for 60Hz electrical systems
• Rated for operation in ambient temperatures up to 40°C
• Matches the original form, fit, and function of compatible FA-frame installations
• Built to last for continued service in existing electrical systems


Technical Specifications

• Part Number: FA24030AC Old Style

• Frame Type: FA

• Product Type: Molded Case Circuit Breaker

• Amperage: 30 Amps

• Poles: 2

• Trip Type: Thermal-Magnetic

• Interrupting Rating: 14kA @ 480VAC; 18kA @ 240VAC

• Frequency: 60Hz

• Mounting Style: I-Line Plug-In

• Phase Configuration: A-C

• HACR Rated: Yes

• Operating Temperature: 40°C

• Dimensions:
  • Width: 3.00 in.
  • Height: 8.75 in.
  • Depth: 4.38 in.
• Approximate Shipping Weight: 6.25 lbs.


Material Compliance and Certifications

The FA24030AC Old Style is intended for use in compatible FA-frame I-Line electrical distribution equipment that matches its electrical ratings and mounting configuration. It carries a HACR Type designation for compatible HVAC and refrigeration applications. Before installation, verify that the breaker's ratings and configuration match the equipment. Installation should always follow the equipment manufacturer's instructions, the National Electrical Code (NEC), and applicable local electrical codes.

Where It Works Best

The FA24030AC Old Style is commonly found in compatible electrical distribution systems serving:

• Commercial buildings
• Industrial facilities
• Manufacturing plants
• Office buildings
• Schools and universities
• Healthcare facilities
• Warehouses and distribution centers
• Compatible FA-frame I-Line panelboards
• Compatible I-Line switchboards
• HVAC and refrigeration equipment requiring an HACR-rated breaker
