EQ9683 - 150Amp Circuit Breaker

EQ9683 - 150Amp Circuit Breaker

The Siemens EQ9683 is a 150 Amp, 2-pole main circuit breaker designed for use in compatible Siemens and legacy ITE EQ96 load centers and panelboards. Featuring a thermal magnetic trip design, it provides protection against overloads and short circuits while matching the original electrical specifications of the equipment it was designed to serve.

Because replacement breakers need to match the existing panel—not just electrically, but physically as well—the EQ9683 is built as a form, fit, and functional replacement. Its plug-in mounting design installs in compatible EQ96 panels and occupies four single-pole spaces, making it suitable for applications that require the original footprint and configuration.

Key Features and Benefits

• Siemens EQ9683 main circuit breaker
• 150 Amp current rating
• 2-pole configuration
• Thermal magnetic trip protection against overloads and short circuits
• Plug-in mounting for compatible EQ96 load centers and panelboards
• Occupies four (4) single-pole panel spaces
• 22kA interrupting rating at 240VAC
• Form, fit, and functional replacement for compatible Siemens and legacy ITE equipment
• Helps maintain the original panel configuration
• Built to last for long-term service in compatible electrical systems


Technical Specifications

• Manufacturer: Siemens

• Part Number: EQ9683

• Product Type: Main Circuit Breaker

• Series/Type: EQ96

• Amperage: 150 Amps

• Poles: 2

• Interrupting Rating: 22kA @ 240VAC

• Trip Type: Thermal Magnetic

• Mounting Style: Plug-In

• Panel Space Required: Four (4) Single-Pole Spaces

• Dimensions:
  • Width: 4.00 in.
  • Height: 3.18 in.
  • Depth: 2.50 in.
• Approximate Shipping Weight: 3.00 lbs.


Material Compliance and Certifications

• Designed for use in compatible Siemens and legacy ITE EQ96 load centers and panelboards
• Manufactured to meet the specifications of the original breaker design
• Intended as a form, fit, and functional replacement for approved applications
• Installation should be completed in accordance with applicable electrical codes and manufacturer requirements


Where It Works Best

The Siemens EQ9683 is commonly used when replacing a 150 Amp main breaker in compatible Siemens and legacy ITE EQ96 load centers and panelboards. It is a practical choice for maintaining existing residential, commercial, or light industrial electrical systems where matching the original breaker type, ratings, and panel layout is important. Before installation, verify that the panel model and breaker specifications are compatible with this part.
