EP3200 - 200Amp Circuit Breaker

EP3200 - 200Amp Circuit Breaker

The Siemens EP3200 is a 200 Amp, 3-pole EDA circuit breaker designed for use in compatible Siemens load centers and electrical distribution equipment. Featuring a thermal magnetic trip unit, it provides protection against both overloads and short circuits while the common-trip design disconnects all three poles simultaneously when a fault is detected. Whether you're replacing an existing breaker during maintenance or restoring original equipment, selecting the correct amperage, pole configuration, voltage rating, and breaker type is essential.

Key Features and Benefits

• Siemens EP3200 circuit breaker
• 200 Amp current rating
• Three-pole configuration
• EDA breaker type
• Thermal magnetic trip protection
• Common-trip operation disconnects all three poles during fault conditions
• Rated for 240VAC applications
• 10kA interrupting capacity
• Designed for compatible Siemens load centers and electrical distribution equipment
• Matches the original form, fit, and function of compatible Siemens equipment


Technical Specifications

• Manufacturer: Siemens

• Part Number: EP3200

• Breaker Type: EDA

• Number of Poles: 3

• Current Rating: 200 Amps

• Voltage Rating: 240VAC

• Rated Voltage (Phase-to-Phase): 240V

• Rated Voltage (Phase-to-Ground): 240V

• Interrupting Rating: 10kA @ 240VAC

• Trip Unit: Thermal Magnetic

• Trip Configuration: Common Trip

• Mounting Style: EDA Load Center Main Breaker

• Dimensions:
  • Length: 7.874"
  • Width: 2.756"
  • Height: 3.937"
• Approximate Net Weight: 0.485 lb.

• Country of Origin: Dominican Republic


Material Compliance and Certifications

• Manufactured by Siemens
• Thermal magnetic protection for overload and short-circuit conditions
• Designed for use in compatible Siemens load centers and electrical distribution equipment
• Commodity Code: 8536200020
• Export Classification: ECCN EAR99


Where It Works Best

The Siemens EP3200 is intended for compatible Siemens load centers and other electrical distribution equipment that require a 200 Amp, 3-pole EDA circuit breaker. It is commonly used during maintenance, equipment repairs, and replacement projects where matching the original breaker's electrical ratings and physical configuration is important.
