EJB34035 - 35 Amp Circuit Breaker

EJB34035 - 35 Amp Circuit Breaker

When you need dependable circuit protection for a compatible Square D NF panelboard, the Square D EJB34035 is built to get the job done. This 35 Amp, 3-pole thermal-magnetic circuit breaker helps protect electrical systems from overloads and short circuits while delivering the consistent performance commercial and industrial facilities expect. Its bolt-on mounting design creates a secure connection within the panel, making it a practical choice for maintenance work, equipment upgrades, or replacing an existing breaker with a matching specification.

One feature electricians appreciate is the built-in trip indicator, which makes it easy to see when a breaker has tripped due to a fault. That saves valuable troubleshooting time and helps get equipment back online more quickly.

Key Features and Benefits

• 35 Amp current rating for dependable branch circuit protection
• Three-pole configuration for three-phase electrical systems
• Bolt-on design creates a secure installation in compatible NF panelboards
• Thermal-magnetic trip unit responds to overloads and short circuits
• Built-in trip indicator helps speed up troubleshooting
• Rated for operation up to 480Y/277V AC
• High interrupting capacity, up to 100 kA at applicable voltage ratings

Technical Specifications

• Manufacturer: Square D

• Catalog Number: EJB34035

• Series: 125A Frame EDB / EGB / EJB

• Frame Type: E-Frame

• Current Rating: 35 Amps

• Number of Poles: 3

• Maximum Operating Voltage: 480Y/277V AC

• Mounting Style: Bolt-On

• Trip Unit: Thermal-Magnetic

• Protection Type: Overload and Short Circuit

• Interrupting Ratings:
  • 100 kA @ 120V AC
  • 100 kA @ 120/240V AC
  • 100 kA @ 240V AC
  • 65 kA @ 277V AC
  • 65 kA @ 480Y/277V AC
• Trip Indicator: Yes

• Wire Range:
  • Copper: AWG 14–2/0
  • Aluminum: AWG 12–2/0
• Panel Compatibility: Square D NF Panelboards

• Dimensions:
  • Height: 5.66 in. H
  • Width: 2.94 in. W
  • Depth: 4.05 in. D
• Weight: Approximately 4 lbs


Material Compliance and Certifications

The Square D EJB34035 is cULus Listed, HACR rated, HID rated, and TAA compliant. It is calibrated for operation in ambient temperatures up to 40°C (104°F) and is intended for use in compatible Square D NF panelboards. For safe and reliable performance, installation should always follow the National Electrical Code (NEC) and all applicable local electrical codes.

Where It Works Best

The EJB34035 is a solid choice for a variety of commercial and industrial electrical systems, including:

• Square D NF panelboards
• Office buildings
• Retail facilities
• Manufacturing plants
• Warehouses
• Healthcare facilities
• Schools and universities
• Commercial HVAC equipment
• HID lighting installations
• Electrical maintenance and replacement projects
