EHD3080 80A Circuit Breaker

EHD3080 80A Circuit Breaker

Introducing the Eaton EHD3080 Series C Molded Case Circuit Breaker, an essential component for robust electrical protection in industrial and commercial applications. This three-pole, 80 Amp circuit breaker is engineered for reliability and safety, featuring fixed thermal and magnetic trip mechanisms to ensure precise protection against overloads and short circuits. Designed with an F-frame structure, the EHD3080 delivers exceptional performance with a frequency rating of 50/60 Hz, making it versatile for various electrical systems.

Key Features and Benefits:

• High Performance: The EHD3080 offers an interrupt rating of 18 kAIC at 240 Vac and 14 kAIC at 480 Vac, providing robust protection against high fault currents.
• Durability: Constructed with Eaton’s renowned quality, this circuit breaker ensures long-lasting durability, supported by a one-year warranty from the date of installation or eighteen months from the date of shipment.
• Easy Installation: Designed for load side connections, it simplifies installation and integration into existing electrical systems.

Technical Specifications:

• Amperage Rating: 80 A
• Trip Type: Fixed thermal, fixed magnetic
• Number of Poles: 3
• Frame Type: F-frame
• Series: C
• Frequency Rating: 50/60 Hz
• Interrupt Rating: 18 kAIC at 240 Vac, 14 kAIC at 480 Vac
• Dimensions: 3.38 in (Length) x 6 in (Height) x 4.13 in (Width)
• Weight: 4.3 lb

Material Compliance and Certifications:

• Certifications: UL Listed, ensuring compliance with national safety standards.

Suitability:

• The Eaton EHD3080 is ideal for use in a wide range of applications, from commercial buildings to industrial plants. Its robust construction and high interrupt rating make it suitable for protecting electrical circuits in harsh environments where reliability and safety are paramount. Whether you’re upgrading an existing electrical system or installing a new one, the EHD3080 provides the performance and protection you need.
