EHD3060 60A Circuit Breaker

EHD3060 60A Circuit Breaker

The Eaton EHD3060 Series C complete molded case circuit breaker is a robust and reliable solution designed for a wide range of applications, ensuring superior performance and safety. Engineered with fixed thermal and fixed magnetic trip types, this F-frame circuit breaker is built to handle demanding electrical loads, making it ideal for commercial and industrial settings. With a three-pole configuration and a current rating of 60 amps, it operates efficiently at both 50/60 Hz frequencies. The EHD3060 provides exceptional interrupting capacity, with ratings of 14 kAIC at 480 Vac and 18 kAIC at 240 Vac, ensuring protection against overcurrent and short circuits.

Key Features and Benefits:

• Reliable Performance: The EHD3060 is designed to deliver consistent and reliable performance, ensuring safety and protection in various electrical applications.
• High Interrupting Capacity: With interrupting ratings of 14 kAIC at 480 Vac and 18 kAIC at 240 Vac, this breaker is capable of handling significant fault conditions, providing enhanced protection.
• Durable Construction: Built with a molded case, the EHD3060 ensures durability and longevity, even in harsh environments.
• Ease of Installation: Featuring load side terminals, this breaker is straightforward to install and integrate into existing electrical systems.

Technical Specifications:

• UPC: 786679317167
• Frame Type: F-frame
• Current Rating: 60 Amps
• Poles: Three
• Frequency Rating: 50/60 Hz
• Interrupting Rating: 14 kAIC at 480 Vac, 18 kAIC at 240 Vac
• Trip Type: Fixed thermal, fixed magnetic
• Dimensions: 3.38 in (L) x 6 in (H) x 4.13 in (W)
• Weight: 4.5 lb

Material Compliance and Certifications:

• Compliance: The Eaton EHD3060 circuit breaker is UL Listed, ensuring it meets the highest standards for safety and performance. Its construction and materials comply with industry regulations, making it a trusted choice for electrical protection. The one-year warranty from the date of installation or eighteen months from the date of shipment provides additional assurance of quality and reliability.

Suitability:

• The EHD3060 is well-suited for a variety of applications, including commercial, industrial, and institutional environments where reliable overcurrent protection is critical. Its high interrupting capacity makes it ideal for systems with significant electrical loads, ensuring safety and minimizing downtime in case of faults.
