EHD3035L - 35Amp Circuit Breaker

EHD3035L - 35Amp Circuit Breaker

When you need a 35 Amp, 3-pole molded case circuit breaker that matches the specifications of your existing electrical system, the Eaton EHD3035L Series C is designed to provide the protection and compatibility your application requires. This complete Series C EHD molded case circuit breaker combines a T186 thermal-magnetic trip unit with dependable overload and short-circuit protection for commercial and industrial power distribution systems. Built to last and manufactured to Eaton's published specifications, the EHD3035L is intended as a form, fit, and functional replacement for installations originally designed to use this catalog number, helping maintain compatibility without requiring modifications to existing equipment.

Whether replacing an existing breaker during scheduled maintenance or restoring an electrical distribution system to its original design, the Eaton EHD3035L delivers the ratings, configuration, and compatibility needed to help keep your system operating as intended.

Key Features and Benefits

• 35 Amp continuous current rating
• Three-pole configuration for three-phase electrical systems
• Eaton Series C complete molded case circuit breaker
• EHD circuit breaker design
• T186 thermal-magnetic trip unit provides overload and short-circuit protection
• Rated for 50/60 Hz electrical systems
• Line and load terminals for compatible installations
• Built to last for dependable long-term service
• Designed as a form, fit, and functional replacement where an EHD3035L circuit breaker is specified

Technical Specifications

• Manufacturer: Eaton

• Catalog Number: EHD3035L

• Product Type: Molded Case Circuit Breaker

• Series: Series C

• Circuit Breaker Type: EHD

• Frame Type: Complete Breaker

• Amperage Rating: 35 Amps

• Number of Poles: 3

• Trip Unit: T186 Thermal-Magnetic

• Frequency: 50/60 Hz

• Interrupt Rating: 18 kAIC at 240 VAC; 14 kAIC at 480 VAC

• Terminals: Line and Load

• Dimensions:
  • Length: 3.38 in.
  • Width: 4.13 in.
  • Height: 6.00 in.
• Weight: 5 lbs

• UPC: 786679399668


Material Compliance and Certifications

• UL Listed
• Manufactured to Eaton specifications
• Covered by Eaton's published warranty policy

Where It Works Best

The Eaton EHD3035L is commonly used in commercial buildings, industrial facilities, manufacturing plants, institutional buildings, and other three-phase electrical distribution systems where a 35 Amp, 3-pole Series C molded case circuit breaker is specified. It is well suited for compatible switchboards, panelboards, distribution equipment, motor control applications, and OEM electrical systems that require this exact breaker configuration.
