EHD3035 - 35Amp Circuit Breaker

EHD3035 - 35Amp Circuit Breaker

When you need a 35 Amp, 3-pole molded case circuit breaker that matches the specifications of your existing electrical system, the Eaton EHD3035 Series C is designed to provide the protection and compatibility your application requires. Built for commercial and industrial power distribution, this complete F-frame circuit breaker combines a T186 thermal-magnetic trip unit with dependable overcurrent and short-circuit protection to help keep electrical systems operating safely.

Whether you're replacing a worn breaker during routine maintenance or sourcing the correct part for an existing installation, the Eaton EHD3035 delivers the ratings, dimensions, and configuration needed to keep your electrical distribution equipment operating as intended.

Key Features and Benefits

• 35 Amp continuous current rating
• Three-pole configuration for three-phase electrical systems
• Eaton Series C complete molded case circuit breaker
• F-frame design for compatible installations
• T186 thermal-magnetic trip unit provides overload and short-circuit protection
• Rated for 50/60 Hz electrical systems
• Load-side terminals
• Built to last for dependable long-term service
• Designed as a form, fit, and functional replacement where an EHD3035 circuit breaker is specified

Technical Specifications

• Manufacturer: Eaton

• Catalog Number: EHD3035

• Product Type: Molded Case Circuit Breaker

• Series: Series C

• Circuit Breaker Type: EHD

• Frame: F Frame

• Frame Type: Complete Breaker

• Amperage Rating: 35 Amps

• Number of Poles: 3

• Trip Unit: T186 Thermal-Magnetic

• Frequency: 50/60 Hz

• Interrupt Rating: 18 kAIC at 240 VAC; 14 kAIC at 480 VAC

• Terminals: Load Side

• Dimensions:
  • Length: 3.38 in.
  • Width: 4.13 in.
  • Height: 6.00 in.
• Weight: 4.3 lbs


Material Compliance and Certifications

• UL Listed
• Manufactured to Eaton specifications
• Covered by Eaton's published warranty policy

Where It Works Best

The Eaton EHD3035 is commonly used in commercial buildings, industrial facilities, manufacturing plants, and institutional electrical systems where a 35 Amp, 3-pole Series C F-frame molded case circuit breaker is required. It is well suited for panelboards, switchboards, distribution equipment, motor control applications, and other electrical systems that specify this exact breaker.
