EHD3015 - 15Amp Circuit Breaker

EHD3015 - 15Amp Circuit Breaker

The Eaton EHD3015 Series C molded-case circuit breaker is a 3-pole, 15-amp breaker designed to provide dependable overcurrent protection in compatible commercial and industrial electrical systems. Built on Eaton's proven F-frame platform, this complete breaker features a T186 thermal-magnetic trip unit that responds to both overloads and short circuits, helping safeguard connected equipment and electrical circuits during everyday operation. Whether you're performing scheduled maintenance, replacing a worn breaker, or restoring existing equipment, the EHD3015 is built to last and is designed as a form, fit, and functional replacement for compatible Eaton Series C installations.

Key Features and Benefits

• 15 Amp current rating for compatible branch circuit protection applications.
• Three-pole molded case circuit breaker for three-phase electrical systems.
• Genuine Eaton Series C complete breaker built on the F-frame platform.
• T186 thermal-magnetic trip unit provides protection against overloads and short circuits.
• Load side terminals designed for compatible equipment configurations.
• Rated for 50/60 Hz AC electrical systems.
• UL Listed to meet recognized electrical safety standards.
• Built to last for dependable operation in properly maintained electrical systems.
• Designed as a form-fit-and-function replacement for compatible Eaton Series C applications.

Technical Specifications

• Manufacturer: Eaton

• Series: Series C

• Catalog Number: EHD3015

• UPC: 786679317044

• Product Type: Complete Molded Case Circuit Breaker

• Circuit Breaker Type: EHD

• Circuit Breaker Frame Type: Complete Breaker

• Frame: F

• Amperage Rating: 15A

• Number of Poles: 3

• Trip Type: T186 Thermal-Magnetic

• Frequency Rating: 50/60 Hz

• Interrupt Rating:
  • 18 kAIC at 240 Vac
  • 14 kAIC at 480 Vac
• Terminals: Load Side

• Dimensions:
  • Width: 4.13 in.
  • Length: 6.00 in.
  • Depth: 3.38 in.
• Weight: 4.15 lb

• Certification: UL Listed


Material Compliance and Certifications

The Eaton EHD3015 is UL Listed and manufactured to Eaton's specifications for the Series C family of molded case circuit breakers. It is intended for installation in compatible electrical distribution equipment designed to accept an EHD F-frame complete breaker. To help ensure proper fit and operation, verify that the catalog number, frame type, amperage, pole configuration, interrupting rating, trip unit, and terminal configuration match the original equipment before installation.

Where It Works Best

The EHD3015 is an excellent choice for maintaining compatible electrical distribution systems in commercial buildings, industrial facilities, manufacturing plants, healthcare campuses, educational institutions, and other three-phase power environments. It's commonly used in compatible panelboards, switchboards, motor control centers, HVAC equipment, and branch circuit applications where a 15 Amp, 3-pole Eaton Series C F-frame molded case circuit breaker is required.
