EHB1030L - 30Amp Circuit Breaker

EHB1030L - 30Amp Circuit Breaker

If you're maintaining an older electrical panel, finding the correct replacement breaker can make all the difference. The EHB1030L is a 1-pole, 30 Amp thermal-magnetic molded-case circuit breaker designed for compatible EHB series electrical panels manufactured before 1989. Instead of changing the panel or adopting newer components, this breaker is intended to match the original form, fit, and function, helping to keep your existing electrical system configured as it was designed.

The breaker uses a thermal-magnetic trip mechanism, which responds to overloads over time while also reacting quickly to short-circuit conditions. It features a 14kA interrupting rating at 277VAC, a non-interchangeable trip unit, and comes with both line and load terminals, making it suitable for compatible replacement applications.

Key Features and Benefits

• Form, fit, and functional replacement for compatible EHB series circuit breakers
• 30 Amp current rating for branch circuit protection
• Single-pole thermal-magnetic molded case circuit breaker
• Thermal-magnetic trip mechanism helps protect against overloads and short circuits
• Non-interchangeable trip unit maintains the original breaker configuration
• Rated for operation in 40°C (104°F) ambient temperatures
• Includes both line and load terminals
• Designed for electrical panels manufactured before 1989
• Built to last for continued use in compatible legacy electrical systems


Technical Specifications

• Part Number: EHB1030L

• Type: EHB

• Product Type: Thermal-Magnetic Molded Case Circuit Breaker

• Poles: 1

• Current Rating: 30 Amps

• Interrupting Rating: 14kA @ 277VAC

• Trip Unit: Non-Interchangeable Thermal-Magnetic

• Ambient Temperature Rating: 40°C

• Terminals Included: Line and Load

• Dimensions:
  • Width: 1.38 inches
  • Height: 6.00 inches
  • Depth: 3.38 inches
• Approximate Shipping Weight: 3.00 lbs.

• Compatible Panels: Panels manufactured before 1989


Material Compliance and Certifications

• Thermal-magnetic molded case circuit breaker construction
• Rated for operation in 40°C ambient environments
• Manufactured to the published electrical ratings for this model
• Designed for installation in compatible EHB series electrical equipment
• Includes factory-configured line and load terminals
• Installation should be completed in accordance with applicable electrical codes and the equipment manufacturer's recommendations
• Always verify compatibility with your existing electrical system before installation


Where It Works Best

• The EHB1030L is commonly used in commercial, industrial, and institutional facilities that continue to operate equipment designed for EHB series circuit breakers. It's a good fit for lighting panels, branch circuits, distribution panels, and other legacy electrical systems requiring a 1-pole, 30 Amp thermal-magnetic breaker with a 14 kA interrupting rating at 277 VAC.
• If your goal is to keep an existing panel in service without changing its original design, using a breaker with the correct specifications is essential. The EHB1030L provides the form, fit, and functional compatibility needed for designated applications, helping maintain the intended operation of compatible electrical equipment.
