EHB1015 - 15Amp Circuit Breaker

EHB1015 - 15Amp Circuit Breaker

When you need a 15 Amp replacement circuit breaker for a compatible legacy electrical system, the EHB1015 molded-case circuit breaker delivers the form, fit, and function your equipment was originally designed for. This 1-pole thermal-magnetic circuit breaker is built for panels manufactured before 1989, making it a practical choice for maintaining existing electrical distribution systems without changing the original breaker configuration.

Designed with a non-interchangeable trip unit, the EHB1015 helps protect branch circuits from both overloads and short circuits while matching the specifications required by compatible equipment. It features a 14kA interrupting capacity at 277VAC, is rated for operation at 40°C ambient temperatures, and includes load terminals to simplify installation.

Key Features and Benefits

• Designed as a form, fit, and functional replacement for compatible EHB circuit breakers
• 15 Amp current rating for dependable branch circuit protection
• Single-pole (1-pole) design for compatible electrical distribution systems
• Thermal-magnetic trip mechanism helps protect against overloads and short circuits
• Non-interchangeable trip unit maintains the original breaker configuration
• Rated for operation in 40°C ambient temperatures
• Load terminals included for added installation convenience
• Designed specifically for electrical panels manufactured before 1989
• Durable molded case construction built to last


Technical Specifications

• Part Number: EHB1015

• Type: EHB

• Product Type: Molded Case Circuit Breaker

• Poles: 1

• Current Rating: 15 Amps

• Trip Unit: Thermal-Magnetic (Non-Interchangeable)

• Interrupting Capacity: 14kA @ 277VAC

• Ambient Temperature Rating: 40°C

• Load Terminals: Included

• Panel Compatibility: Panels manufactured before 1989

• Dimensions:
  • Width: 1.38 inches
  • Height: 6.00 inches
  • Depth: 3.38 inches
• Approximate Shipping Weight: 3.00 lbs.


Material Compliance and Certifications

• Molded case circuit breaker construction
• Manufactured to the published electrical ratings for this model
• Intended for installation in compatible electrical distribution equipment
• Designed for use in electrical panels manufactured before 1989
• Installation should be completed in accordance with applicable electrical codes and manufacturer requirements
• Always confirm compatibility before installation


Where It Works Best

The EHB1015 is an excellent choice for maintaining existing commercial, industrial, and institutional electrical systems that use EHB series circuit breakers. It's commonly installed in compatible panelboards, lighting panels, branch circuits, and power distribution equipment where a 1-pole, 15 Amp thermal-magnetic circuit breaker with a 14 kA interrupting rating at 277 VAC is required.
