EGS3080FFB - 80Amp Circuit Breaker

EGS3080FFB - 80Amp  Circuit Breaker

The Eaton EGS3080FFB is an 80 Amp, three-pole molded case circuit breaker designed to provide dependable circuit protection in compatible Eaton Series G EG frame electrical distribution systems. Whether you're replacing an existing breaker as part of scheduled maintenance or restoring a system to its original specifications, this complete breaker delivers the proper form, fit, and function for compatible installations. Featuring bolt-on terminals for a secure connection and a T186 thermal-magnetic trip unit, the EGS3080FFB automatically responds to overloads and short circuits to help protect electrical equipment and branch circuits. Built to last, this breaker is a practical choice for commercial and industrial facilities that need a reliable replacement while maintaining the integrity of existing electrical systems.

Key Features and Benefits

• 80 Amp continuous current rating
• Three-pole molded case circuit breaker
• Designed for compatible Eaton Series G EG frame equipment
• Complete breaker assembly for form, fit, and functional replacement
• Bolt-on terminals provide a secure electrical connection
• T186 thermal-magnetic trip unit helps protect against overloads and short circuits
• Designed for 50/60 Hz electrical distribution systems
• Built to last for dependable operation in properly maintained electrical systems


Technical Specifications

• Catalog Number: EGS3080FFB

• Manufacturer: Eaton

• Series: Series G

• Product Type: Molded Case Circuit Breaker

• Circuit Breaker Type: EG

• Frame: EG

• Frame Type: Complete Breaker

• Amperage Rating: 80 Amps

• Number of Poles: 3

• Voltage Rating: 600Y/347 VAC

• Frequency Rating: 50/60 Hz

• Trip Type: T186 Thermal-Magnetic

• Terminal Type: Bolt-On

• Interrupting Ratings:
  • 85 kAIC @ 240 VAC
  • 35 kAIC @ 480 VAC
  • 22 kAIC @ 600Y/347 VAC
• Dimensions:
  • Height: 5.5 in.
  • Width: 3 in.
  • Depth: 2.99 in.
• Weight: 2.91 lb


Material Compliance and Certifications

The EGS3080FFB meets recognized industry standards for safety and compliance.

• UL Listed
• CSA Certified
• IEC Rated
• CE Marked


Where It Works Best

• Commercial office buildings
• Manufacturing facilities
• Industrial plants
• Healthcare facilities
• Educational campuses
• Warehouses and distribution centers
• Electrical distribution panels
• Branch circuit protection applications
• Existing power distribution systems designed for compatible Eaton Series G EG frame breakers
