EGS3060FFB - 60Amp Circuit Breaker

EGS3060FFB - 60Amp Circuit Breaker

The Eaton EGS3060FFB is a 60 Amp, three-pole molded case circuit breaker designed to provide dependable circuit protection in compatible Eaton Series G EG frame electrical distribution systems. Whether you're replacing an existing breaker during scheduled maintenance or restoring equipment to its original specifications, this complete breaker delivers the proper form, fit, and function for compatible installations. Its bolt-on terminals create a secure electrical connection, while the T186 thermal-magnetic trip unit automatically responds to overloads and short circuits to help protect connected equipment and branch circuits.

Designed for 60 Amp applications and rated for 600Y/347 VAC, the EGS3060FFB is suitable for 50/60 Hz electrical distribution systems. It provides interrupting ratings of 85 kAIC at 240 VAC, 35 kAIC at 480 VAC, and 22 kAIC at 600Y/347 VAC, making it well suited for a variety of commercial and industrial installations.

Key Features and Benefits

• 60 Amp continuous current rating
• Three-pole molded case circuit breaker
• Designed for compatible Eaton Series G EG frame equipment
• Complete breaker assembly for form, fit, and functional replacement
• Bolt-on terminals for secure installation
• T186 thermal-magnetic trip unit
• Helps protect electrical systems from overloads and short circuits
• Designed for 50/60 Hz electrical distribution systems
• Built to last for dependable service in properly maintained electrical systems


Technical Specifications

• Catalog Number: EGS3060FFB

• Manufacturer: Eaton

• Series: Series G

• Product Type: Molded Case Circuit Breaker

• Frame: EG

• Frame Type: Complete Breaker

• Amperage Rating: 60 Amps

• Number of Poles: 3

• Voltage Rating: 600Y/347 VAC

• Frequency Rating: 50/60 Hz

• Trip Type: T186 Thermal-Magnetic

• Terminal Type: Bolt-On

• Interrupting Ratings:
  • 85 kAIC @ 240 VAC
  • 35 kAIC @ 480 VAC
  • 22 kAIC @ 600Y/347 VAC
• Dimensions:
  • Height: 5.5 in.
  • Width: 3.0 in.
  • Depth: 2.99 in.
• Weight: Approximately 2.9 lbs.


Material Compliance and Certifications

The EGS3060FFB is manufactured to meet recognized electrical safety and compliance standards.

• UL Listed
• CSA Certified
• IEC Rated
• CE Marked


Where It Works Best

• Commercial office buildings
• Manufacturing facilities
• Industrial plants
• Healthcare facilities
• Educational campuses
• Warehouses and distribution centers
• Electrical distribution panels
• Branch circuit protection applications
• Existing power distribution systems designed for compatible Eaton Series G EG frame breakers
