EGS3020FFB - 20Amp Circuit Breaker

EGS3020FFB - 20Amp Circuit Breaker

The Eaton EGS3020FFB is a 20 Amp, three-pole molded case circuit breaker designed for use in compatible Eaton Series G EG frame electrical distribution systems. Whether you're replacing an existing breaker during scheduled maintenance or restoring equipment to its original configuration, this complete breaker delivers the proper form, fit, and function for compatible installations. Featuring a bolt-on terminal design, it provides a secure connection, while the T186 thermal-magnetic trip unit automatically responds to overloads and short circuits to help protect electrical equipment and branch circuits. Built to last and engineered for dependable operation, the EGS3020FFB is an excellent choice for electricians, maintenance teams, and facility managers who want to maintain the integrity of existing electrical systems without making unnecessary modifications.

Key Features and Benefits

• 20 Amp continuous current rating
• Three-pole molded case circuit breaker
• Designed for compatible Eaton Series G EG frame equipment
• Complete breaker assembly for form, fit, and functional replacement
• Bolt-on terminals for secure installation
• T186 thermal-magnetic trip unit
• Helps protect electrical systems from overloads and short circuits
• Designed for 50/60 Hz electrical distribution systems
• Built to last for dependable service in properly maintained electrical systems


Technical Specifications

• Catalog Number: EGS3020FFB

• Manufacturer: Eaton

• Series: Series G

• Product Type: Molded Case Circuit Breaker

• Frame: EG

• Frame Type: Complete Breaker

• Amperage Rating: 20 Amps

• Number of Poles: 3

• Voltage Rating: 600Y/347 VAC

• Frequency Rating: 50/60 Hz

• Trip Type: T186 Thermal-Magnetic

• Terminal Type: Bolt-On

• Interrupting Ratings:
  • 85 kAIC @ 240 VAC
  • 35 kAIC @ 480 VAC
  • 22 kAIC @ 600Y/347 VAC
• Dimensions:
  • Height: 5.5 in.
  • Width: 3.0 in.
  • Depth: 2.99 in.
• Weight: Approximately 2.9 lbs.


Material Compliance and Certifications

The EGS3020FFB is manufactured to meet recognized electrical safety and compliance standards.

• UL Listed
• CSA Certified
• IEC Rated
• CE Marked


Where It Works Best

• Commercial office buildings
• Manufacturing facilities
• Industrial plants
• Healthcare facilities
• Educational campuses
• Warehouses and distribution centers
• Electrical distribution panels
• Branch circuit protection applications
• Existing power distribution systems designed for compatible Eaton Series G EG frame breakers
